Widely used in medical testing, robotics, mold assembly and other industrial test, measurement and control systems;
It is also suitable for various industrial weighing systems such as testing machines, truck scales, hopper scales and so on.
Material: stainless steel, alloy steel
Size: Flanged, Range can be customized
KWT1D75H series is a kind of bilayer through-hole struture load cell,it is a improved version based on KWT1D55H series to meet more measurement application scene. It adopts the multi-strain gauge bridge design, which can significantly optimize the performance and reduce the influence of external load on the sensor performance. This series has a low structure, and its very suitable for applications in environments with limited vertical space. This is a load cell that can handle eccentric loads and still maintain high accuracy and reliability.
Stainless steel material, cover plate sealing, electronic weighing system
● Stainless steel material
● Cover plate seal
● Electronic weighing system
KWT1D118(gland)series is a kind of spoke structure load cell, which can measure pull and compression force value. It is similar with KWT1D78 series that designed for the application of tension and compression. It has two versions about material can be choosen, alloy steel or high strength stainless steel material.
The sensor can meet the test requirements of a wide range of sensors, with a range of 100kN~200kN.
Alloy steel materials, cover plate sealing, electronic weighing system
● Alloy Steel Material
● Cover Plate Seal
● Electronic Weighing System
Widely used in testing machines, truck scales, hopper scales, various industrial weighing systems.
Material: stainless steel, alloy steel
Size: Spoke type, Other ranges can be customized
Aluminum alloy material, surface anodizing treatment, silicone rubber sealing, electronic weighing system
● Aluminum alloy material
● Surface anodizing treatment
● Silicone rubber seal
● Electronic weighing system
Stainless steel material, cover plate sealing, electronic weighing system
● Stainless steel material
● Cover plate seal
● Electronic weighing system
High precision, with good temperature and time stability, low height, good rigidity, and strong resistance to eccentric loads.
Widely used in belt scales, hopper scales, storage scales, material tanks, material mechanics testing machines, labor safety testing equipment, etc
KWT1D100H is a kind of ring symmetric force sensor, which adopts a hollow ring double-spoke structure. It is based on strain principle with an excellent and sensititive internal strain area to distritube the strain guege. It can provide high-precision measurement results and better protect the strain gauge. Also realizing bending moment compensation and lateral force compensation for sensors through special structural design and circuit design. It will improve the production efficiency with easy and fast installation.
Product description:
Capacity ：10kg~50Ton
Alloy Steel
High stability
Can be installed in small spaces
Stable anti-interference signal
Widely used in electronic truck scales hopper scales, automotive testing equipment other electronic weighing or force measuring fields
