KWT1D75H series is a kind of bilayer through-hole struture load cell,it is a improved version based on KWT1D55H series to meet more measurement application scene. It adopts the multi-strain gauge bridge design, which can significantly optimize the performance and reduce the influence of external load on the sensor performance. This series has a low structure, and its very suitable for applications in environments with limited vertical space. This is a load cell that can handle eccentric loads and still maintain high accuracy and reliability.

1. Made of alloy steel or stainless steel

2. Suitable for belt weigher, hopper scale and other weighing devices

3. Good steel performance and high accuracy

Widely used in medical testing, robotics, mold assembly and other industrial test, measurement and control systems;
It is also suitable for various industrial weighing systems such as testing machines, truck scales, hopper scales and so on.

Material: stainless steel, alloy steel

Size: Flanged, Range can be customized

KWT1D55H series can provide reliable test results even in harsh industrial environments. The accurate and reliable prouction process ensures that it has a small linear error. The extremely high rigidity makes the sensor fit for scientific research and rapid production processes.

KWT1D100H  is a kind of ring symmetric force sensor, which adopts a hollow ring double-spoke structure. It is based on strain principle with an excellent and sensititive internal strain area to distritube the strain guege. It can provide high-precision measurement results and better protect the strain gauge. Also realizing bending moment compensation and lateral force compensation for sensors through special structural design and circuit design. It will improve the production efficiency with easy and fast installation.

• Rail-type installation is convenient
• Input reverse polarity protection and output protection
• Through 4000V EMC. Strong anti-interference ability
• Long-term stability and high precision
• Can be equipped with various strain gauge sensors

KWT1D65 series is a kind of high-accuracy and multi-functions spoke type sensor. It has a unique integral multi-beam shear design that can withstand high external load, which makes the load cell with good stiffness and excellent dynamic response ability.

The ZMLB is spoke type load cell designed for both tension and compression force measurement. Nickel plated alloy steel can make protection class achieve IP67. The shear beam structure gives load cell high performance of linearity. Zhimin offers ODM&OEM service.

Nickel plated alloy steel IP67

1.Alloy steel;

2.Low height, good rigidity, high precision, load-deflection resistance is strong;

3.Suitable for electronic belt scale, hopper scale, storage scale, tank scales, mechanics of materials testing machine, etc. weighing devices.
