1. Made of alloy steel or stainless steel

2. Suitable for belt weigher, hopper scale and other weighing devices

3. Good steel performance and high accuracy

• NS-TH3 series spoke type load cell structure;
• Simple, robust and resistant to lateral forces and eccentric loads
• Low center of gravity and easy installation;
• It is widely used in automatic control systems as automatic control components such as weighing and force measurement.

The sensor can meet the test requirements of a wide range of sensors, with a range of 100kN~200kN.

Widely used in testing machines, truck scales, hopper scales, various industrial weighing systems.

Material: stainless steel, alloy steel

Size: Spoke type, Other ranges can be customized

• Rail-type installation is convenient
• Input reverse polarity protection and output protection
• Through 4000V EMC. Strong anti-interference ability
• Long-term stability and high precision
• Can be equipped with various strain gauge sensors
• digital smart amplifier

KWT1D65 series is a kind of high-accuracy and multi-functions spoke type sensor. It has a unique integral multi-beam shear design that can withstand high external load, which makes the load cell with good stiffness and excellent dynamic response ability.

KWT1D55H series can provide reliable test results even in harsh industrial environments. The accurate and reliable prouction process ensures that it has a small linear error. The extremely high rigidity makes the sensor fit for scientific research and rapid production processes.

1.Alloy steel;

2.Low height, good rigidity, high precision, load-deflection resistance is strong;

3.Suitable for electronic belt scale, hopper scale, storage scale, tank scales, mechanics of materials testing machine, etc. weighing devices.

KWT1D60 is a kind of high accuracy and overload capacity load cell. The product has a built-in embedded circuit for real-time data accquisition and calculation, and can measure the value of force fastly. This series can also match the measuring requirements of multiple range.

KWT1D75H series is a kind of bilayer through-hole struture load cell,it is a improved version based on KWT1D55H series to meet more measurement application scene. It adopts the multi-strain gauge bridge design, which can significantly optimize the performance and reduce the influence of external load on the sensor performance. This series has a low structure, and its very suitable for applications in environments with limited vertical space. This is a load cell that can handle eccentric loads and still maintain high accuracy and reliability.
