High stability and reliability.

Applicable to: measurement and control system of testing machine and other force value.

The ZMMC4 is donut type force sensor which is available in a wide range of standard capacities from 5kg through to 2000kg. The ZMMC4 is configured for compression force measurement acting on cylinders, bolts or shafts. A range of internal through-hole diameters is available. The outer and inner diameter can be customized based on client’s requirements.

Stainless steel construction

big capacity load cell,compression force load cell,tension force load cell,hydraulic equipment force load cell

Model: MLC409
Category: Compression Load Cell
Range: 40t,50t,60t,100t,150t,200t,300t
Dimension: 197*160mm; 240*230/305*326mm; 415*358mm
Material: alloy steel, stainless steel
Characteristic: big capacity load cell,compression force load cell,tension force load cell,hydraulic equipment force load cell

big capacity load cell, compression force load cell, hydraulic equipment force load cell

Model: MLC407
Category: Compression Load Cell
Load range:600ton
Dimension:256*225mm
Material: alloy steel
Cable: Φ6mm*12m
Characteristic: big capacity load cell, compression force load cell, hydraulic equipment force load cell

• Capacities: 0-12.5kN up to 0-540kN
• Output: 1.5mV/V nominal
• Environmental Protection: IP66
• Accuracy: <±1.5%/RC typical
• Custom-Sized Versions Available
• Low Height & Compact – To easily fit where space is limited.
• Optimum Performance Guaranteed – Its high-frequency response captures transient measurement fast.
• Long-Life and Low Maintenance – With its rugged stainless steel construction.
• Adapt It For Your Application – With our customisation service.
• Submersible Versions Available – Perfect for marine and offshore applications.

MLC401E Hydraulic Press Forging Press Large Range Column Weighing Sensor 300t

Model: MLC401E
Category: Column weighing sensor
Measurement range: 20t, 25t, 30t, 40t, 50t, 60t, 70t, 100t, 150t, 200t, 300t, 400t
Size: 76 * 82.6mm; 125 * 142 millimeters; 223 * 250mm
Materials: alloy steel, stainless steel
Application: Automobile scale, electronic floor scale, hydraulic press, hydraulic press, dynamometer, large-scale weighing sensor

safety limiter weight sensor, overload load cell, pin load cell, pin force load cell

Model: MLC162
Category: Bridge load cell
Range: 2,3,5,10,15,20,30,40,50,100t
Dimensions: ± 58 * 128mm, ± 68 * 128mm
Material: alloy steel, stainless steel
Characteristic: safety limiter load cell, overload load cell, pin load cell, pin force sensor
