9223 S-Force Sensor
Technical parameters
Dimensions
The Model 102 load cells combines both a compact form and high precision to offer a superior tension force transducer. The one-piece S-shaped design achieves a maximum non-linearity of 0.02 % full scale for load ranges from 20 kg to 1000 kg. Additional features include minimal temperature effects on zero and span of 0.002 %/°C and 0.002 %/°C, respectively.
Tension and compression load cell can bear both tension and pressure, with good output symmetry, high eccentric load resistant, compact structure and complete specifications. Strain gauge load cell can be applied for batching scale, crane scales and other special weighing instruments.
High precision, bidirectional bearing, easy to install. It is suitable for measuring and controlling the force value of batching scale, hook scale, electromechanical scale, packaging scale, material mechanics testing machine and other equipment.
이 제품은 낮은 높이와 높은 안정성, 정밀성을 갖춘 구조로 설계되었으며, 다양한 계량 및 자동화 테스트 장비에 폭넓게 활용됩니다.
S type load cell can bear both tension and pressure, with good stability, good output symmetry, high accuracy, low temperature drift, compact structure and complete specifications. Micro load cell is suited to use in restricted spaces.
Miniature load cell can bear both tension and compression force, with metal-foil strain gauge, all stainless steel, small size, 1.0±0.2mV/V sensitivity. Miniature tension and compression load cell is used for force tester, riveting machine, laminator and welding machine.
S-type sensor, Aluminum alloy material, Surface anodizing treatment, Silicone rubber seal, Measurement of tensile force, Electronic weighing system
● S-type sensor
● Aluminum alloy material
● Surface anodizing treatment
● Silicone rubber seal
● Measurement of tensile force
● Electronic weighing system
The PSD-X1 Load Cell is a tailored weighing solution designed for compact, precision-focused applications—ideal for integration into smart shelves, electronic price computing scales, and small-platform electronic scales. Its specialized cantilever-beam structure and lightweight yet durable build make it a reliable choice for retail, logistics, and small-scale industrial scenarios where space efficiency and accurate weight measurement are key.
With the function of anti-overload protection. High precision, bidirectional bearing, easy to install. It is suitable for measuring and controlling the force value of batching scale, hook scale, electromechanical scale, packaging scale, material mechanics testing machine and other equipment.
The PSD-F6 Load Cell is a high-performance weighing component engineered for industrial bulk weighing—specialized for integration into belt scales (including skirted or standard belt conveyors) and hopper scales. Its unique bellows-type cantilever-beam structure, heavy-duty alloy steel build, and smart functional design ensure reliable, accurate weight measurement for dynamic or static bulk materials, making it ideal for mining, chemical processing, logistics, and agricultural sectors.
High-quality S-type load cells for sale are used for tension and compression and are available in a variety of capacities from 200kg to 5 tons. Constructed of durable stainless steel with a sensitivity range of 2.0 to 3.0 ±10% mV/V and a response frequency of 1k Hz, it provides accurate measurements even in harsh conditions, making it a reliable and cost-effective choice for tension and compression measurements in industrial environments.
The Model 127 load cells combines both a compact form and high precision to offer a superior tension force transducer. The one-piece S-shaped design achieves a maximum non-linearity of 0.03 % full scale for load ranges of 50 kg and 100 kg.
