Widely used in auto press assembly, automated assembly, 3C product testing;
New energy product assembly, medical testing, robotics, mold assembly And other industrial test, measurement and control systems.
Material: stainless steel
Size: Low height, Small Amount
Model 34 precision miniature load cells measure both tension and compression load forces of 1000 g to 1000 lb. These models are our highest accuracy, rugged miniature load cells. Model 34’s welded, stainless steel construction is designed to eliminate or reduce to a minimum, the effects of off-axis loads. (The internal construction assures excellent long-term stability for ranges 1000 grams and above.) A modification permits this model to be completely welded for underwater applications. The Model 34 tension/compression load cell has female threads attachments. High accuracies of 0.15 % to 0.25 % full scale are achieved. Each bonded strain gage unit is built of welded 17-4 PH stainless steel for additional ruggedness. All load cells with ranges from 1 kg to 10 lb have an electrical balance module in the lead wire (approximately 1 in x .087 in thick). This balance module does not have to be the same temperature as the transducer.
Эластомер сенсора изготовлен из алюминиевого сплава, герметизирован клеем, поверхность обработана прозрачным анодированием. Степень защиты достигает IP65.
Widely used in auto press assembly, automated assembly, 3C product testing;New energy product assembly, medical testing, robotics, mold assembly;
And other industrial test, measurement and control systems.
Material: 17-4PH stainless steel
Size: High speed, low deflection
Used in injection molding and extrusion manufacturing processes;
Automobile pressing, 3C product testing, new energy product assembly,
Medical testing, robotics, and other industrial test, measurement, and control systems.
Used in auto press assembly, automatic assembly, 3C product testing;New energy product assembly, medical testing, robotics;
Mold assembly and other industrial test, measurement and control systems, etc.
Material: stainless steel
Size: Small size, Large range, Shock proof
Widely used in auto press assembly, automated assembly, 3C product testing;
New energy product assembly, medical testing, robotics, etc & High dynamic response frequency.
Material: stainless steel, High precision
Size: Slim design, Small size
Widely used in auto press assembly, automated assembly, 3C product testing,
New energy product assembly, medical testing, robotics;High dynamic response frequency.
Material: stainless steel, Customizable high temperature performance
Size: Small size, Low height
Widely used in automobiles, robots and medical equipment;Used in situations where space is limited;
It is also used for research and development in various industries.
Material: stainless steel, High temperature performance can be determine
Size: Ultra-thin size, Low height
Model 13 (compression only) subminiature load cell is designed to measure load ranges from 150 g to 1000 lb. With subminiature dimensions, including diameters from 0.38 in to 0.75 in and heights of 0.13 in to 0.25 in, these units are easily incorporated into systems having limited space. Model 13 combines high frequency response and low deflection to achieve a combined non-linearity and hysteresis of 0.25 % to 0.5 % full scale. A balance module is included in the load cell’s lead wire cable for temperature compensation and should not be removed.
Widely used in auto press assembly, automated assembly, 3C product testing;
New energy product assembly, medical testing, robotics, mold assembly;
And other industrial test, measurement and control systems, etc.
Material: stainless steel, High precision
Size: Small size, Flat mountable
Model 11 (tension/compression) subminiature load cell is designed to measure load ranges from 150 g to 1000 lb. With subminiature dimensions, including diameters from .50 in to 0.75 in and height of 0.38 in, these units are easily incorporated into systems having limited space. The model achieves a non-linearity and hysteresis of 0.5 % full scale respectively and a frequency response of up to 58 kHz. A balance module is included in the load cell’s lead wire cable for zero balance, and should not be removed.
