Products tagged “Compression Load Cells”
- Capacities: 0-10kg up to 0-500kg
- Output: 2mV/V
- Environmental Protection: IP68
- High Accuracy: <±0.02%/RC
- Optional Vessel Mounts
- Ideal for Accurate Batch Hopper Weighing Applications
- Hermetically Sealed & Immersion Protected for Food Hygiene Environments
- Optimum Accuracy Guaranteed with Vessel Mounts
- Optimise Signal Integrity and Reduce Noise – With our Integrated Signal Conditioning Options
- Capacities: 0-10N up to 0-500N
- Output: 2mV/V
- Environmental Protection: IP50
- Accuracy: <±0.05%/RC
- Compact Size
- Miniature Size – Ideal for Low-Range Monitoring
- Superior Accuracy Guaranteed
- Ideal for general industrial use
- Wide Range of Instrumentation
- Load Cell Capacities: 0-5kN up to 0-1000kN
- Load Cell Output: 2mV/V
- High Accuracy Load Cell: <±0.05%/RC
- SGA Output: 0-5Vdc, 0-10Vdc, 4-20mA, 0-20mA, ±5Vdc or ±10Vdc
- High Speed: Bandwidth 6kHz max.
- Supplied Calibrated & Ready to Use
- DSCC Compression Load Cell + SGA Strain Gauge Amplifier
- High-Frequency Response – Ideal for Crash Test Walls
- Load Cell Customisation Available
- Sensor Options Include: Fatigue-Rated Versions, IP67 Rated Versions, IP68 Submersible Versions
- Load Cell Capacities: 0-5kN up to 0-1000kN
- Load Cell Output: 2mV/V
- High Accuracy Load Cell: <±0.05%/RC
- 7-Digit LCD Display (±9999999)
- 2 Ranges / Engineering Units
- Optional RS232 Serial Data Output
- IP65 Environmental Protection
- DSCC Compression Load Cell + TR150 Digital Readout
- Supplied Calibrated & Ready to Use
- IP65 Dust-Tight and Splash-Proof Protection
- 7 Digit LCD Display for High Accuracy Applications
- Calibration in 2 Separate Engineering Units Possible
- Peak-Capture Capability @ 25Hz Sampling Rate
- Load Cell Customisation Available Including: Fatigue-Rated Versions, IP67 Rated Versions, IP68 Submersible Versions
- Load Cell Capacities: 0-5kN up to 0-1000kN
- Load Cell Output: 2mV/V
- High Accuracy Load Cell: <±0.05%/RC
- Easy To Read Backlit Display
- 2 Calibration Channels
- IP64 Dust Tight Environmental Protection For Display
- DSCC Compression Load Cell + TRX Digital Readout
- TRX Supports Two Different Sensor Inputs, With The Option To Increase That To Six (Only One Sensor At A Time)
- Optional Data Logging, Graphical Analysis And Export Options Available When Connected To PC TRX Toolkit Software
- Measurement rate up to 2,400 SPS
- TEDS Enabled
- Load Cell Customisation Available Including: Fatigue-Rated Versions, IP67 Rated Versions, IP68 Submersible Versions
- Load Cell Capacities: 0-50kg up to 0-50,000kg
- Load Cell Output: 2mV/V
- Accuracy: <±0.15%
- Integral Load Button
- 6-Digit LED Display (±999999)
- 10 Point Linearisation
- CBES Compression Load Cell + INT4-L Load Cell Display
- Supplied Calibrated & Ready to Use
- 6 Digit LED Display for High Accuracy Applications
- 10 Point Linearisation to Guarantee Superb Accuracy
- IP65 Dust-Tight and Splashproof Protection for Industrial Environments
- Load Cell & Display Customisation Available
- Load Cell Capacities: 0-50kg up to 0-50,000kg
- Load Cell Output: 2mV/V
- Accuracy: <±0.15%
- Integral Load Button
- Easy To Read Backlit Display
- 2 Calibration Channels
- IP64 Dust Tight Environmental Protection For Display
- CBES Compression Load Cell + TRX Digital Readout
- TRX Supports Two Different Sensor Inputs, With The Option To Increase That To Six (Only One Sensor At A Time)
- Optional Data Logging, Graphical Analysis And Export Options Available When Connected To PC TRX Toolkit Software
- Measurement Rate Up To 2,400 SPS
- TEDS Enabled
- Load Cell & Display Customisation Available
- Capacities: 0-2te up to 0-1000te
- Output: 1.5mV/V
- Sealed to IP67 (IP68 submersible versions available)
- Stainless Steel Construction
- Optional Amplifier Output & Integral Connector
- Can be Supplied with Loading Cap & Mounting Base
- Long-Term Submersible Versions Available – Ideal for marine and offshore applications.
- Lower Height Versions Available – To fit within your specific application.
- Fast and Easy Installation – With our loading cap and mounting bases.
- Immersion protected to 1 metre – for up to 30 mins.
- Carry Handles Supplied for Units Over 200t
- Get it Fast – Shorter delivery times on lower capacities.
- Capacities: 0-12.5kN up to 0-540kN
- Output: 1.5mV/V nominal
- Environmental Protection: IP66
- Accuracy: <±1.5%/RC typical
- Custom-Sized Versions Available
- Low Height & Compact – To easily fit where space is limited.
- Optimum Performance Guaranteed – Its high-frequency response captures transient measurement fast.
- Long-Life and Low Maintenance – With its rugged stainless steel construction.
- Adapt It For Your Application – With our customisation service.
- Submersible Versions Available – Perfect for marine and offshore applications.
- Capacities: 0-50N/0-1Nm to 0-250kN/0-2500Nm
- Accuracy: <±0.1%/RC
- Low Crosstalk
- Environmental Protection: IP65
- Custom Versions Available
- Reduced Cross Talk Guarantees Optimum Performance
- Ideal for use in the Geotechnical and Materials Testing Sectors
- Customisation Available to Suit Your Specific Application
- Ideal for use in Most Industrial Environments
- Capacities: 0-2te up to 0-1500te
- Output: 2mV/V (1.5mV/V on 500te+)
- Accuracy: <±0.10%
- IP67 & IP68 Submersible Options
- Domed-Top Versions Available
- Superior Accuracy Guaranteed – BS EN ISO 376 calibration certification if required.
- Submersible Versions Available – Perfect for marine and off-shore applications.
- Let us do the work for you – The CCDHA can be supplied as a complete system.
- Capacities: 0-1te up to 0-150te
- Output: 1.5mV/V
- Environmental Protection: IP66
- Submersible Versions Available (IP68)
- Special Capacities To 1500te+
- Tough Marine and Underwater Submersible Versions Available
- High-Pressure Water Jet Protection as Standard – For use in Most Industrial Environments
- Optimise Signal Integrity and Reduce Noise – With our Integrated Signal Conditioning Options
- Capacities: 0-50N up to 0-50kN
- Output: 0.75mV/V to 2mV/V
- Fully Submersible: IP68 to 10m
- Accuracy: <±0.15%/RC (0.05% typical)
- Optional Integral Amplifier
- Ideal for any Freshwater Application
- Fully Submersible Long-Term Immersion Protected
- Underwater Protection Guaranteed Thanks to ‘O’ Ring Sealing
- Greater Underwater Depth Ratings Available for Deep Sea Applications
- Special Versions Alternative Construction Materials for Seawater and other Corrosive or Aggressive Media.
- Capacities: 0-25N up to 0-250N
- Ø9mm and 2.9mm Height
- Environmental Protection: IP53
- Accuracy: <±0.25%/RC
- Integral Load Button
- Very Compact – At Ø9mm x 2.9mm height it easily fits into the smallest of spaces.
- Save on Installation Time – Ideal for retrofitting into existing designs.
- Optimum Performance Guaranteed – With its integral load button.
- Ideal for Compression Measurement with Limited Space.
- Capacities: 0-100N up to 0-20kN
- Output: 2mV/V nominal (1.5mV/V on 0-100N)
- Environmental Protection: IP65
- Accuracy: <±0.5%/RC
- Integral Load Button
- Very Compact – At Ø30mm x 12mm height it easily fits into the smallest of spaces.
- Save on Installation Time – Ideal for retrofitting into existing designs.
- Optimum Performance Guaranteed – From its integral load button
- Let us do the hard work for you – The CDFM3 can be supplied with our wide range of instrumentation.
