Aluminum alloy material, surface anodizing treatment, silicone rubber sealing, electronic weighing system
● Aluminum alloy material
● Surface anodizing treatment
● Silicone rubber seal
● Electronic weighing system
The sensor can meet the test requirements of a wide range of sensors, with a range of 100kN~200kN.
The sensor can meet the test requirements of a wide range of sensors, with a range of 100kN~200kN.
Stainless steel material, cover plate sealing, electronic weighing system
● Stainless steel material
● Cover plate seal
● Electronic weighing system
Stainless steel material, cover plate sealing, electronic weighing system
● Stainless steel material
● Cover plate seal
● Electronic weighing system
Product description:
Capacity ：30~1000kg
Material: stainless steel
Defend grade: IP66.
Application: It is widely used for electronic truck scales, hopper scales, automotive testing equipment other electronic weighing or force measuring fields and other automation fields.
KWT1D100H is a kind of ring symmetric force sensor, which adopts a hollow ring double-spoke structure. It is based on strain principle with an excellent and sensititive internal strain area to distritube the strain guege. It can provide high-precision measurement results and better protect the strain gauge. Also realizing bending moment compensation and lateral force compensation for sensors through special structural design and circuit design. It will improve the production efficiency with easy and fast installation.
KWT1D118(gland)series is a kind of spoke structure load cell, which can measure pull and compression force value. It is similar with KWT1D78 series that designed for the application of tension and compression. It has two versions about material can be choosen, alloy steel or high strength stainless steel material.
Widely used in testing machines, truck scales, hopper scales, various industrial weighing systems.
Material: stainless steel, alloy steel
Size: Spoke type, Other ranges can be customized
KWT1D60 is a kind of high accuracy and overload capacity load cell. The product has a built-in embedded circuit for real-time data accquisition and calculation, and can measure the value of force fastly. This series can also match the measuring requirements of multiple range.
Stainless steel material, cover plate sealing, electronic weighing system
● Stainless steel material
● Cover plate seal
● Electronic weighing system
KWT1D55H series can provide reliable test results even in harsh industrial environments. The accurate and reliable prouction process ensures that it has a small linear error. The extremely high rigidity makes the sensor fit for scientific research and rapid production processes.
