KWT1D65 series is a kind of high-accuracy and multi-functions spoke type sensor. It has a unique integral multi-beam shear design that can withstand high external load, which makes the load cell with good stiffness and excellent dynamic response ability.

• NS-TH1 series load cell is composed of combined S-beam structure and metal foil strain gauge, with overload protection device;
• It has the advantages of high measurement accuracy, good temperature characteristics and stable operation;
• It is widely used in dynamic and static measurement of various structures and primary instruments of various electronic scales.

• NS-TH3 series spoke type load cell structure;
• Simple, robust and resistant to lateral forces and eccentric loads
• Low center of gravity and easy installation;
• It is widely used in automatic control systems as automatic control components such as weighing and force measurement.

Widely used in medical testing, robotics, mold assembly and other industrial test, measurement and control systems;
It is also suitable for various industrial weighing systems such as testing machines, truck scales, hopper scales and so on.

Material: stainless steel, alloy steel

Size: Flanged, Range can be customized

Product description:
Capacity ：30~1000kg
Material: stainless steel
Defend grade: IP66.
Application: It is widely used for electronic truck scales, hopper scales, automotive testing equipment other electronic weighing or force measuring fields and other automation fields.

High precision, with good temperature and time stability, low height, good rigidity, and strong resistance to eccentric loads.
Widely used in belt scales, hopper scales, storage scales, material tanks, material mechanics testing machines, labor safety testing equipment, etc

The ZMLB is spoke type load cell designed for both tension and compression force measurement. Nickel plated alloy steel can make protection class achieve IP67. The shear beam structure gives load cell high performance of linearity. Zhimin offers ODM&OEM service.

Nickel plated alloy steel IP67

1. Made of alloy steel or stainless steel

2. Suitable for belt weigher, hopper scale and other weighing devices

3. Good steel performance and high accuracy

KWT1D100H  is a kind of ring symmetric force sensor, which adopts a hollow ring double-spoke structure. It is based on strain principle with an excellent and sensititive internal strain area to distritube the strain guege. It can provide high-precision measurement results and better protect the strain gauge. Also realizing bending moment compensation and lateral force compensation for sensors through special structural design and circuit design. It will improve the production efficiency with easy and fast installation.

KWT1D63 sensor is a tensile and compressive force transducers with good performance and great overload capacity, it has high-precision embedded integrated circuit, when the load on the force sensor can be collected and solved in real time.

Widely used in auto press assembly, automated assembly, 3C product testing;
New energy product assembly, medical testing, robotics, mold assembly;And other industrial test, measurement and control systems.

Material: stainless steel

Size: Spoke type

• Rail-type installation is convenient
• Input reverse polarity protection and output protection
• Through 4000V EMC. Strong anti-interference ability
• Long-term stability and high precision
• Can be equipped with various strain gauge sensors
