HPS-FT060S
| Model | HPS-FT060S | Working temperature | -10~+55℃ |
| System structure | Digital output + Adaptor | Power consumption | 0.5W |
| Measuring range |
±1000N（Fxy） | Communication interface*1 | Ethernet、EtherCAT、RS485、Analog output |
| ±1400N（Fz） | Weight*4 | ≈502g | |
| ±30Nm（Mxy） | Size | 87×78(diameter)x28.5mm | |
| ±30Nm（Mz） | Power supply | DC 12V~24V | |
| Resolution | 0.01(%FS)（Fxy） | External connector type | Cold-pressed terminal |
| 0.01(%FS)（Fz） | Data output rate*2 | 2700Hz(max) | |
| 0.01(%FS)（Mxy） | Protection degree | IP64（Customizable: IP67） | |
| 0.01(%FS)（Mz） | Overload capacity*3 | 350% | |
| Non-linearity | ＜1.25(%FS) | Crosstalk | <2(%FS) |
