• Measuring range: 0-5m
• Weight: 800g (cable pulling mechanism)
• Weight (pulling rope): 1.2g/m
• Length of each turn of the rope: 385mm
• Shell material: plastic, aluminum alloy
• Spring resilience: 3.3-4.4N
• Cable diameter: 0.6mm
• Rope material: high elastic 316 stainless steel rope
• Linearity: ≤±2mm
• Protection class: IP50
• Acceleration: 10 m/s²
• Roller circumference: 385mm
• Name: Economical encoder cable box BSL-GA130 series
• Can be customized on request

• Measuring range: 0-1.2m
• Weight (drawing rope): 0.58g/m
• Length of each turn of the rope: 250mm
• Spring resilience: 3.3-4.4N
• Pull rope diameter: 0.6mm
• Protection class: IP50
• Pull rope acceleration: 5m/s²
• Length of each turn of the rope: 150mm
• Actual length of the rope: 1.2m
• Name: Economical encoder cable box BSL-GA55A series
• Can be customized on request

• Measuring range: 0-30m
• Weight: 9.8kg (cable traction mechanism)
• Weight (pulling rope): 2.6g/m
• Length of each turn of the rope: 333mm
• Housing Material: Aluminum (anodized) plastic
• Spring resilience: 10-20N
• Cable diameter: 0.8mm
• Industrial Precision Encoder Cable Box BSL-MA130-30 Series
• Can be customized on request

• Measuring range: up to 8000mm
• Output signal: AB phase, ABZ phase
• Resolution: 0.01, 0.02, 0.04, 0.08mm / pulse
• Working voltage: 10-30V DC, 5V DC
• Accuracy: +/-0.05% (full scale), +/-1 pulse
• Measuring wheel circumference: 400mm
• Pulling speed: maximum 1m/s
• Pull rope tension: 5-10N
• Weight: <5KG
• Product Name: Cable Displacement Sensor CESI-L8000 Series
• Can be customized on request

• Measuring range: 0-10m
• Weight: 5.8kg (rope traction mechanism)
• Weight (draw rope): 7.1g/m
• Length of each turn of the rope: 333mm
• Actual length of the rope: 10.2m
• Housing Material: Aluminum (anodized) plastic
• Spring resilience: 10-20N
• Pull rope diameter: 1.2mm
• Rope speed: 40m/s²
• Product Name: Industrial Precision Encoder Cable Box BSL-MA130-10 Series
• Can be customized on request

ZMMA-YS is mini type force transducer, widely used on UTM and compression&tension force applications.

Features:

Both compression and tension

• Measuring range: up to 3000mm
• Measuring wheel circumference: 200mm
• Pulling speed: maximum 0.6m/s
• Pull rope tension: 5N
• Weight: <2KG
• Accuracy: +/-0.05%FS
• Power supply voltage: 10-30V DC, 5V DC
• Resolution 0.01, 0.02, 0.04, 0.08 mm / pulse
• Product Name: Cable Displacement Sensor CESI-M3000 Series
• Can be customized on request

• Measuring range: up to 500mm
• Measuring wheel circumference: 80mm
• Pulling speed: maximum 0.6m/s
• Pull rope tension: 3N
• Protection class: IP54
• Material: aluminum alloy
• Rope speed: maximum 0.6m/s
• Product Name: Pull Wire Displacement Sensor CWP-S500 Series
• Can be customized on request

Measuring range: 90°~43200°

Nonlinearity: 0.05%FS

• Measuring range: up to 500mm
• Measuring wheel circumference: 100mm
• Pulling speed: maximum 0.6m/s
• Resolution: 0.01, 0.02, 0.04, 0.08 mm / pulse
• Accuracy: +/-0.05%FS
• Power supply voltage: 10-30V DC, 5V DC
• Pull rope tension: 3N
• Weight: <0.5KG
• Product Name: Cable Displacement Sensor CESI-S500 Series
• Can be customized on request

• Measuring range: up to 400mm
• Measuring wheel circumference: 40mm
• Speed: Max 0.6m/s
• Pull rope tension: 3N
• Weight: <0.5KG
• Protection class: IP54
• Material: aluminum alloy
• Vibration: 10Hz to 2000Hz
• Wire diameter specification: 0.6mm highly flexible 304 stainless steel wire rope
• Product name: Cable displacement sensor CWP-S400 series
• Can be customized on request

• Measuring range: up to 1500mm
• Measuring wheel circumference: 150mm
• Speed: Max 0.8m/s
• Pull rope tension: 5N
• Weight: <0.7KG
• Linearity: 0.1%
• Protection class: IP54
• Product name: Cable displacement sensor CWP-S1500 series
• Can be customized on request
