Widely used in auto press assembly, automated assembly, 3C product testing;
New energy product assembly, medical testing, robot, mold assembly and other industrial test, measurement and systems.

Material: stainless steel, Aluminum alloy

Size: Overload Protection High precision

KWT1C80/130 series is a kind of column structure load cell, which both sides designed with double flanges to locating the position of mounting. The middle of load cell adopts through-hole design to meet the special requirements in the use process. This series has two size, the diameter of KWT1C80 is 80mm, the range is 25kN to 50kN, the KWT1C130 is 130mm and its range is 100kN. We also support customization on size and range as your needs.

This product has a simple structural design and low cost. The design of its sealing membrane changes the cumbersome process of requiring a matching housing in the past, overcomes the defect of the housing of traditional sensors being easily damaged due to deformation, and greatly improves the sealing performance of the sensor. Compared with traditional column sensors, this type of sensor achieves relatively high accuracy in linearity, lateral resistance, torsion resistance, and azimuth error.
Traditional column sensors are widely used in various electronic weighing devices such as track scales, hopper scales, platform scales, etc.

Column type, hermetically sealed structure, IP68 compression, fast response, strong anti-overload, upper ball head load bearing.

Simple install, easy to use, suitable for electronic truck scale, dynamic railroad scale and big capacity hopper scale, etc.

KWT1D52H is a big-range compact-design column load cell. It is made of 17-4PH material, and its rated range is 200kN. The sensor has a rasied surface radius to reduce the possibility of off-center load.

KWT1S55 is a small range and high-precision tensile and compressive force sensor. Its main body is designed with an aluminum alloy structure, and its top is equipped with a compressive loading head, which is convenient for customers to apply pressure to the heart.

15-100t IP68 Material Weighing Control For Large Tonnage Tank Applied Weighing Module FA812 is a model of our brand FIBOS FA8-Series, Weighing Module FA812 can be used to measure load ranges from 15t,20t,30t,50t to 100t capacity, it is easy to install and maintan, it supports bolt to avoid overturn, its spherical fittings keep the vertical weighing state.

This product is made of high-quality alloy steel, offering excellent stability and resistance to signal interference. It can be installed in confined spaces and customized to specific requirements, making it widely used for pressure and force measurement in various industrial applications.

• Capacity: 0-2000kg
• Sensitivity: 2.0±0.05mV/V
• Non-linearity 0.05% F.S.
• Repeatability 0.03% F.S.
• Material Stainless steel with nickel plated
• Bi-directional tension and compression
• Can be customized

1.Column Type, hermetically sealed structure, argon-arc welded, good self-centering, fast dynamic response, strong anti-overload capability.

2.Simple to install, easy to use.

3.Suitable for electronic truck scales, railroad scale and big capacity hopper scale, etc.

This column sensor has the advantages of low height, large contact area, high comprehensive accuracy and convenient installation. Different measuring ranges and sizes can be customized.
It is mainly used in various electronic weighing equipment and tensile force detection equipment with large stress area, such as press-fitting equipment, mobile phone assembly, small pressure platform,
testing machine, press-fitting machine, oil press, cold and hot press, electronic hook scale hopper scale, etc.

SC9N은 무거운 계량 어플리케이션에 이상적인 컬럼형 폼팩터로 제작된 압축 로드셀입니다. 5톤에서 30톤까지 다양한 용량으로 제공되며, 대칭형 폼팩터로 설치 및 장착이 간편합니다.

The SC9N is a compression load cell built in the a column style form factor ideal for heavy weighing applications. Available in capacities from 5 Tonnes to 30 Tonnes, its symmetric form factor allow for easy installation and mounting.
