SANTWELL has a reasonable structure and unique appearance which is designed by our R&D technicians. Made of high-quality time-tested raw materials, Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells has some excellent performance. Moreover, it is made based on customers’ needs and industry trends, so it largely meets the needs of users and is highly valuable.
Shipping: Support Sea freight · Land freight
Customization: Customized logo (Min. Order: 100 Pieces),Customized packaging (Min. Order: 100 Pieces),Graphic customization (Min. Order: 100 Pieces)
Technical Parameter
|
Rated Load
|
0.5~20t
|
|
Sensitivity
|
2.0000±0.002mV/V
|
|
Total Error
|
±0.2%F.S
|
|
Creep(30minutes)
|
±0.2%F.S
|
|
Recommended Excitation Voltage
|
5V~18V(AC or DC)
|
|
Maximum Excitation Voltage
|
24V(AC or DC)
|
|
Zero Balance
|
±1%F.S
|
|
Input Impedance
|
380±10Ω
|
|
Output Impedance
|
350±5Ω
|
|
Insulation Impedance
|
≥5000MΩ
|
|
Safe Overload
|
150%F.S
|
|
Ultimate Overload
|
200%F.S
|
|
Operating Temperature Range
|
(-30~+70)℃
|
|
Compensated Temperature Range
|
(-20~+60)℃
|
|
Temperature Effect On Load
|
±0.02%F.S/10℃
|
|
Temperature Effect On Zero
|
±0.02%F.S/10℃
|
|
Construction
|
Alloy Steel/Aluminum
|
|
Protection Class
|
IP67&IP68
|
|
Citation
|
GB/T7551-2008/OIML R60
|
|
Mode of Connection
|
Input+E:Red
Input-E:Black
Output+S:Green
Output-S:White
|
