Models
Exd2012
Features
Key Features
- Supports Various Communication Interfaces
- RS232 / RS485
- 20mA current loop
- 4–20mA analog output
- PROFIBUS
- MODBUS
- Digital I/O (including switching outputs)
- Other user-defined communication interfaces
- Equipped with Comprehensive Control Functions
- Upper/lower limit alarm
- Set-point alarm
- Set-point output control
- Filling
- Batching
- Additive/subtractive weighing
- Supports custom control functions based on customer requirements
- Compatible with Various Built-in Indicators
- Can integrate a variety of indicators such as Toledo IND320L, IND360, Ohaus Defender 3000, and Transcell T831.
- Touch Button Model Available
- An optional touch-sensitive control panel is available to prevent button failure caused by on-site contaminants (e.g., sticky substances).
- Digital models and models dedicated for bench scales are also available.
Explosion-proof Specifications
- Explosion-proof Certification Rating: Exd[ia IIC Ga]ⅡB T6 Gb
- Applicable Zones: Suitable for use in Zone 1 and Zone 2 where explosive gases are present.
- Applicable Gas Group: IIB T6 rating
