SC218C는 SC218과 같은 원형 버튼 압축 로드셀입니다. SC218C는 SC218의 저가형 버전으로 합금강 구조로만 제공됩니다. 또한, 1톤에서 10톤까지 용량 범위가 제한되어 있습니다.

The SC218C is a round button compression load cell like the SC218. The SC218C is a low cost version of the SC218 and is only available in alloy steel construction. It is also has limited capacity range of 1 Tonne to 10 Tonnes.

1.High precision and compact structure.
2.Environmental Protection IP65 with complete hermetic sealing.
3.It is suitable for force measurement and control, automation equipment, aging testing machine, key stress analysis and power-assisted device in 3C digital production.
4.Compression force Utilizes Metal Foil Strain Gauge Technology.
5.Small size, easy to install in small spaces.

SC29FB는 매우 무거운 압축 하중을 계량하는 어플리케이션에 적합하도록 설계된 대형 버튼형 로드셀입니다. 중량 계량 어플리케이션에서는 설치가 매우 중요하므로, SC29FB는 나사산이 있는 큰 중앙 구멍과 로드셀 본체 주변에 여러 개의 관통 구멍을 가지고 있습니다. 견고하게 설계되어 혹독하고 부식성이 있는 환경에도 설치 가능합니다. 또한, SC29FB는 간편한 설치를 위해 탈착식 방수 커넥터를 갖추고 있습니다.

The SC29FB is large button load cell designed for extremely heavy compression weighing applications. Mounting is critical for heavy weighing applications so SC29FB has a large center hole that is threaded and multiple thru holes around the body of the load cells. It is designed to be rugged and be installed in harsh as well as corrosive environments. The SC29FB also incorporates a removable waterproof connector for simplified installation.

Product description:
Capacity ：100~5000kg
Stainless Steel
High stability
Can be installed in small spaces
Stable anti-interference signal

1.High precision and compact structure.
2.Environmental Protection IP65 with complete hermetic sealing.
3.It is suitable for force measurement and control, automation equipment, aging testing machine, key stress analysis and power-assisted device in 3C digital production.
4.Compression force Utilizes Metal Foil Strain Gauge Technology.
5.Low profile、small、Low Deflection.

Product description:
Capacity ：20,30,50kg
Material: stainless steel
Defend grade: IP66.

SC219는 고압축 계량 어플리케이션에 적합한 원형 버튼형 로드셀입니다. 나사산이 있는 중앙 구멍이 있어 다양한 장착 방식으로 설치할 수 있습니다. 부식성 환경에서의 내구성을 높이기 위해 스테인리스 스틸 재질로도 제작되어 견고합니다.

The SC219 is a round button load cell for heavy compression weighing applications. It has a threaded center hole which makes it possible to install in a variety of different mounting configurations. It rugged is also available in stainless steel for added resistance for corrosive environments.

The ZMMA is compact size and low profile button load cell, constructed from stainless steel and protected from moisture with an epoxy bonded cover. The load cell is easy to be installed with various automation equipment. The dimension can be customized based on client’s requirement.

Stainless steel

SC201GCL은 공간이 제한된 압축 계량 분야에서 널리 사용되는 원형 버튼 로드셀입니다. 독특하고 컴팩트한 디자인으로 최대 IP67 등급의 혹독한 환경에서도 측정이 가능합니다. 부식성 환경에 대한 내구성을 높이기 위해 스테인리스 스틸 소재로도 제작됩니다.

The SC201GCL is a round button load cell popular is compression weighing applications where space is limited. Its unique and compact design allow for measurements is harsh environments with ratings up to IP67. It is also available in stainless steel for added resistance to corrosive environments.

KWT1D40 series is a compact compression force sensor, which can reliably measure the compression force in a limited space. Due to the special structural design, the sensor has a high natural frequency, which can adapt to the high-frequency loads.

SC201은 고압축 응용 분야에 적합하도록 설계된 원형 버튼형 로드셀입니다. 합금강으로 제작된 SC201은 견고하며, 방수 커넥터로 밀봉되어 혹독한 환경에도 설치 가능합니다. 슬림한 바디로 뛰어난 신뢰성과 일관된 정확도를 제공합니다.

The SC201 is a round button load cell designed for heavy compressive applications. Made of alloy steel, the SC201 is rugged and sealed with a water proof connector for installation in harsh environments. It provides great reliability and consistent accuracy is a low profile body.
