| Model Number: | SBKL-(M) | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 0.5-3t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
| Warranty: | 12 months, 1 Year | Customized support: | OEM, ODM, OBM |
| Place of Origin: | ZHEJIANG | Brand Name: | SANTWELL |
| Model Number: | SK210 | Product name: | Weighing Indicator |
| Color: | Black | Material: | ABS Plastic |
| Animal weighing mode: | Have | kg/lb unit: | optional |
| Power: | AC 110-240V or DC | Display: | Red LED |
| Battery: | 6v/4Ah | Application: | platform scale, tank weighing |
| Warranty: | 12 months | Customized support: | OEM, ODM, OBM |
| Place of Origin: | China | Brand Name: | SANTWELL |
| Model Number: | SK210C | Model: | SK210C |
| Display: | 6-digit 20mm LED or 25mm LCD with backlight | Accuracy class: | OIML III |
| Stimulating voltage: | +5 VDC | A/D converting speed: | 80 or 10 SPS |
| Interval: | 1/2/5/10/20/50 | Front panel key: | ON/OFF TOTAL HOLD TARE ZERO SET |
| Working temperature: | -10~40℃ | Storage temperature: | -20~+60℃ |
| Power: | 6V/4Ah rechargeable battery 110/220VAC |
| Warranty: | 12 months | Customized support: | OEM, ODM, OBM |
| Place of Origin: | Zhejiang, China | Brand Name: | SANTWELL |
| Model Number: | SK330 | Model: | SK330 |
| Display: | 6-digit 20mm LED | Accuracy class: | OIML III |
| Stimulating voltage: | +5 VDC | A/D converting speed: | 80 or 10 SPS |
| Interval: | 1/2/5/10/20/50 | Front panel key: | ON/OFF TOTAL HOLD TARE ZERO SET |
| Working temperature: | -10~40℃ | Storage temperature: | -20~+60℃ |
| Power: | 110/220VAC |
We are specialized in manufacturing 15 ton Shear Beam Load Cell Waterproof Force Sensor Canister Load Cells 20 Ton CMAX, etc. for over many years. Manufactured following the strict management system, our 15 ton Shear Beam Load Cell Waterproof Force Sensor Canister Load Cells 20 Ton CMAX has gained a reliable quality. Before its launch, it has passed the tests based on international rules and is certified by several authorities. Santwell is worth the investment for those customers seeking business opportunities. In aspect of the product design, our design team always pays close attention to the customers’ taste and industry trends. Thanks to this, our 15 ton Shear Beam Load Cell Waterproof Force Sensor Canister Load Cells 20 Ton CMAX can fully attract people’s attention with its unique appearance. Moreover, it is excellent performance, making it worth the investment.
| Warranty: | / | Customized support: | ODM |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | SQC | Rated Load: | 100KG |
| Sensitivity: | 2.0000±0.002mv/v | Total Error: | ±0.02%F.S |
| Creep(30 minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V-12V(AC or DC) |
| Maximum Excitation Voltage: | 15V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | ±150%F.S |
| UItimate Overload: | ±200%F.S |
| Model Number: | SQC-(M) | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | SANTWELL |
| Rated Load: | 0.5-3t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd is always dedicated to the research and development, production and sale of the Floor Weighing Scale Load Cell Manufacturer Slim 1 Ton Load Cell Sensor Shear Beam Load Cell 1t. The advancement in technology brings us unlimited benefits which include expanded product advantages.Floor Weighing Scale Load Cell Manufacturer Slim 1 Ton Load Cell Sensor Shear Beam Load Cell 1t is perfect for the area(s) of Force Sensors & Load Cells. Ningbo Santwell Import & Export Co., Ltd are determined that we will invest more in the improvement of R&D strength and gather more talents in the industry, both of which can make great contributions to the long-term development of our company.
| Model Number: | SQC-12K | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Usage: | Weight scale | Theory: | / |
| Output: | Analog output | Description: | Shear beam load cell |
| Rated Load: | 0.5-3t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd always keeps well informed about the technical development and new product R&D, which guarantees we can develop new products on a regular basis. It is designed in accordance with the national standard. Ningbo Santwell Import & Export Co., Ltd aims to become the most influential enterprise in the world. In order to achieve this goal, we will insist on introducing high-tech talents and learning international advanced technology, and strive to improve technical strength and gain the initiative in competition.
| Model Number: | SQC-DSB | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | SANTWELL |
| Usage: | floor scale | Theory: | resistant |
| Output: | 2.0mv/v | Description: | Load cell |
| Rated Load: | (100,150,200,250,300)kg,0.5t,1t,2t,3t,5t,10t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | ST100 |
| Power Supply: | -3.6 mV/V ~ 3.6 mV/V | Display Type: | Double-row 6-position LED display |
| Sensor Type: | Resistance strain sensor | Number of decimal place: | 0,0.0,0.00,0.000,0.0000,0.00000 |
| On-off input voltage: | DC24V | On-off input current: | 4-6mA |
| Division value: | 1, 2, 5, 10, 20, 50 | Max weighing display range: | 999999 |
| Sensor excitation voltage: | DC5V, up to 8 350Ω sensors connection in parallel | A/D switching speed: | ≤400 times / second |
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7530 |
| Power Supply: | -3mV ~ 30mV | Display Type: | 6-digit 10mm LED display |
| Accuracy class: | OIML III | Input voltage: | -3mV ~ 30mV |
| Resolving: | display30000, internal code 2000000 | Excitation voltage: | DC5V |
| Power supply: | AC220V 50/60Hz DC24V |
| Customized support: | OEM, ODM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | XK3190-A9+ |
| Power Supply: | DC8V | Display Type: | 7 bits LED ,7 status indications |
| Model: | A9/ A9P | Input signal range: | 1mV~24mV |
| Load cell Excitation: | Dc 8V | Max. load cell connection: | 8 at 350 ohm |
| Display: | 7 bits LED ,7 status indications | Standard interface: | RS232C , Scoreboard at 20mA current loop Parallel printer |
| Warranty: | 3 years | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | ST110 |
| Power Supply: | -3.6 mV/V ~ 3.6 mV/V | Display Type: | Dual-row LED Display |
| Sensor Type: | Resistance Strain Sensor | Decimals: | 0, 0.0, 0.00, 0.000, 0.0000, 0.00000 |
| On-off input voltage: | DC24V | On-off input current: | 4-6mA |
| Division value: | 1, 2, 5, 10, 20, 50 | Max weighing display range: | 999999 |
| Sensor excitation voltage: | DC5V, Four 350Ω Sensors Can be Connected in Parallel | A/D switching speed: | ≤100 times / second |
| Zero Drift: | ≤10μV/°C |
| Model Number: | BBM-(M) | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 10-500KG | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
| Model Number: | TBA | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated output: | 3t,5t | Sensitivity: | 1.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V (AC o r DC) | Maximum Excitation Voltage: | 24V (AC or DC) |
| Zero Balance: | ±1%F.S | Safe Overload: | 150%F.S |
| Ultimate Overload: | 250%F.S | Working temperature: | (-30~+70)℃ |
| Model Number: | TBB | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Rated Load: | 3t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.5%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
