Showing 113–128 of 136 results
Ningbo Santwell Import & Export Co., Ltd always keeps well informed about the technical development and new product R&D, which guarantees we can develop new products on a regular basis. It is designed in accordance with the national standard. Ningbo Santwell Import & Export Co., Ltd aims to become the most influential enterprise in the world. In order to achieve this goal, we will insist on introducing high-tech talents and learning international advanced technology, and strive to improve technical strength and gain the initiative in competition.
Model Number:
SQC-DSB
Type:
Load Cell
Place of Origin:
Zhejiang, China
Brand Name:
SANTWELL
Usage:
floor scale
Theory:
resistant
Output:
2.0mv/v
Description:
Load cell
Rated Load:
(100,150,200,250,300)kg,0.5t,1t,2t,3t,5t,10t
Sensitivity:
2.0000±0.002mV/V
Total Error:
±0.02%F.S
Creep(30minutes):
±0.02%F.S
Recommended Excitation Voltage:
5V~12V(AC or DC)
Maximum Excitation Voltage:
15V(AC or DC)
Zero Balance:
±1%F.S
Insulation Impedance:
≥5000MΩ
Safe Overload:
150%F.S
Utimate Overload:
200%F.S
Customized support:
OEM
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
LP7530
Power Supply:
-3mV ~ 30mV
Display Type:
6-digit 10mm LED display
Accuracy class:
OIML III
Input voltage:
-3mV ~ 30mV
Resolving:
display30000, internal code 2000000
Excitation voltage:
DC5V
Power supply:
AC220V 50/60Hz DC24V
Customized support:
OEM, ODM
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
XK3190-A9+
Power Supply:
DC8V
Display Type:
7 bits LED ,7 status indications
Model:
A9/ A9P
Input signal range:
1mV~24mV
Load cell Excitation:
Dc 8V
Max. load cell connection:
8 at 350 ohm
Display:
7 bits LED ,7 status indications
Standard interface:
RS232C , Scoreboard at 20mA current loop Parallel printer
Customized support:
OEM
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
ST100
Power Supply:
-3.6 mV/V ~ 3.6 mV/V
Display Type:
Double-row 6-position LED display
Sensor Type:
Resistance strain sensor
Number of decimal place:
0,0.0,0.00,0.000,0.0000,0.00000
On-off input voltage:
DC24V
On-off input current:
4-6mA
Division value:
1, 2, 5, 10, 20, 50
Max weighing display range:
999999
Sensor excitation voltage:
DC5V, up to 8 350Ω sensors connection in parallel
A/D switching speed:
≤400 times / second
Warranty:
3 years
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
ST110
Power Supply:
-3.6 mV/V ~ 3.6 mV/V
Display Type:
Dual-row LED Display
Sensor Type:
Resistance Strain Sensor
Decimals:
0, 0.0, 0.00, 0.000, 0.0000, 0.00000
On-off input voltage:
DC24V
On-off input current:
4-6mA
Division value:
1, 2, 5, 10, 20, 50
Max weighing display range:
999999
Sensor excitation voltage:
DC5V, Four 350Ω Sensors Can be Connected in Parallel
A/D switching speed:
≤100 times / second
Zero Drift:
≤10μV/°C
Model Number:
BBM-(M)
Place of Origin:
Zhejiang, China
Brand Name:
SANTWELL
Usage:
PRESSURE SENSOR
Theory:
Resistance Sensor
Output:
Analog SENSOR
Rated Load:
10-500KG
Sensitivity:
2.0000±0.002mV/V
Total Error:
±0.02%F.S
Creep(30minutes):
±0.02%F.S
Recommended Excitation Voltage:
5V~18V(AC or DC)
Maximum Excitation Voltage:
24V(AC or DC)
Zero Balance:
±1%F.S
Insulation Impedance:
≥5000MΩ
Safe Overload:
150%F.S
Utimate Overload:
200%F.S
Model Number:
TBA
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Usage:
PRESSURE SENSOR
Theory:
Resistance Sensor
Output:
Analog SENSOR
Rated output:
3t,5t
Sensitivity:
1.0000±0.002mV/V
Total Error:
±0.02%F.S
Creep(30minutes):
±0.02%F.S
Recommended Excitation Voltage:
5V~18V (AC o r DC)
Maximum Excitation Voltage:
24V (AC or DC)
Zero Balance:
±1%F.S
Safe Overload:
150%F.S
Ultimate Overload:
250%F.S
Working temperature:
(-30~+70)℃
Model Number:
TBB
Type:
Load Cell
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Rated Load:
3t
Sensitivity:
2.0000±0.002mV/V
Total Error:
±0.5%F.S
Creep(30minutes):
±0.02%F.S
Recommended Excitation Voltage:
5V~12V(AC or DC)
Maximum Excitation Voltage:
15V(AC or DC)
Zero Balance:
±1%F.S
Insulation Impedance:
≥5000MΩ
Safe Overload:
150%F.S
Utimate Overload:
200%F.S
Model Number:
TBQ
Type:
Load Cell
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Usage:
mixing machine
Theory:
resistant strain
Output:
2.0mv/v
Description:
load pin
Rated Load:
5t
Sensitivity:
2.0000±0.002mV/V
Total Error:
±0.5%F.S
Creep(30minutes):
±0.02%F.S
Recommended Excitation Voltage:
5V~18V(AC or DC)
Maximum Excitation Voltage:
24V(AC or DC)
Zero Balance:
±1%F.S
Insulation Impedance:
≥5000MΩ
Safe Overload:
150%F.S
Utimate Overload:
200%F.S
Type:
INDICATOR
Applicable Industries:
Home Use,Office Use,
Other
Showroom Location:
None
Condition:
New
Place of Origin:
China
Warranty:
Unavailable
Key Selling Points:
High Productivity
Marketing Type:
Ordinary Product
Machinery Test Report:
Not Available
Video outgoing-inspection:
Provided
Warranty of core components:
Not Available
Core Components:
Other
Modle:
D10
After Warranty Service:
Online support
Local Service Location:
None
Warranty:
1 YEAR
Customized support:
OEM
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
XK315A6GB
Power Supply:
110-240V
Display Type:
LED/LCD
Material:
Stainless steel
Application:
Truck scale
Operating temperature:
0℃ to 40℃
Storage temperature:
-25℃ to 55℃ 3
Relative humidity:
≤ 85% non condensing
Customized support:
OEM
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
XK315A1-7
Power Supply:
/
Display Type:
6-digit 38mm red LED
Accuracy class:
III
Minimum/maximum load cell impedance:
87 Ω to 1000 Ω
Load cell excitation voltage:
Uexc = 5 V
Cable connection:
4 wires
Fraction of mpe:
pind = 0.5
Minimum input voltage:
Umin = 0.5 Mv
Customized support:
OEM
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
XK315A1GB-3
Power Supply:
6V 2.8AH
Display Type:
6-digit 38mm red LED
Housing:
Stainless steel
Display:
6-digit 20.2mm green LED
Dimensions:
260*222*161mm
Weight:
2.2kg
Inside battery:
6V 2.8AH
Applications:
Electronic platform scale, weighing scale, etc.
Function:
With RS232,WIFI,USB,Warning light
Applies to::
Mechanical scale
Number of connectable sensors:
4*350Ω,8*700Ω
Model:
XK315A1GB-3
Application:
Electronic platform scale, weighing scale, etc.
Color:
As shown
Place of Origin:
Zhejiang,China
Model Number:
XK315A1GB-5-L
Brand Name:
Santwell
Display:
6-digit 25.4mm LCD
Dimensions:
265*162*58mm
Weight:
2.2kg
Inside battery:
6V 2.8AH
Applications:
Electronic platform scale, weighing scale, etc.
Application:
Electronic platform scale, weighing scale, etc.
Color:
As shown
Place of Origin:
Zhejiang,China
Model Number:
XK315A1GB-5
Brand Name:
Santwell
Display:
6-digit 20.2mm green LED
Dimensions:
265*162*58mm
Weight:
2.2kg
Inside battery:
6V 2.8AH
Applications:
Electronic platform scale, weighing scale, etc.
Place of Origin:
Zhejiang, China
Brand Name:
Santwell
Model Number:
XK315A1RB-5
Display Type:
6-digit 38mm red LED
Housing:
Stainless steel
Display:
6-digit 20.2mm red LED
Dimensions:
265*162*58mm
Weight:
2.2kg
Inside battery:
6V 2.8AH
Applications:
Electronic platform scale, weighing scale, etc.
No products were found matching your selection.
