Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
Model Number: | LP7581 | Power Supply: | -3mV ~ 20mV |
Display Type: | 7-digit 20mm LED display | Accuracy class: | OIML III |
Resolving: | display30000, internal code 2000000 | Excitation voltage: | DC5V |
Power supply: | AC110/220 V 50/60 Hz,or 1-12 350Ω analog load cell(s) |
Type: | load cell | Temp.effect on output: | 0.05%F.S./10℃ |
Showroom Location: | MA107A | Input impedance: | 800~1100Ω |
Place of Origin: | China | Insulation: | ≥5000MΩ/100VDC |
Rated output: | 1.5±20%mv/v | Recommended excitaion: | 5-15V |
Zero Balance: | ±0.05mv/v | Maximum excitation: | 20V |
Non Linearity: | 0.5%F.S. | Ultimate overload: | 200%F.S. |
Hysteresis: | 0.2%F.S. | Cable size: | φ3*3000mm |
Repeatability: | 0.2%F.S. | Material: | Stainless steel |
Type: | Load Cell | Modle: | MA107B |
Place of Origin: | China | After Warranty Service: | Online support |
Brand: | Santwell |
Type: | load cell | Operating temperature: | -20 ~+80℃ |
Theory: | Resistance Sensor | Features: | Round shape |
Place of Origin: | China | Brand: | Santwell |
Capacity: | 10/20/30/50/100/200kN | Output: | Analog signal, Analog SENSOR |
Application: | Industrial test and research force measuring | Operating temperature: | -20 ~+80℃ |
Material: | Stainless steel | Non-linearity: | 0.1%F.S |
Hysteresis: | 0.1%F.S |
Having been through countless days and nights,Ningbo Santwell Import & Export Co., Ltd has successfully developed Brand Hm9b QS 30 ton alloy steel analog weight sensor for trucks double shear beam weightbridge load cell. It is bound to catch people’s eyeballs in various fields. After Brand Hm9b QS 30 ton alloy steel analog weight sensor for trucks double shear beam weightbridge load cell launching into the market, we have gained a lot of support and praise. Most customers think that this kind of products are in line with their expectations in terms of appearance and performance. Ningbo Santwell Import & Export Co., Ltd always adhere to the principle of ‘creating values for customers and bringing benefits to stakeholders’. In the process of development, we highly focus on the quality and ensure no flawless product delivered to customers.
Model Number: | QS | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | SantWell |
Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
Output: | Resistance strain | Description: | Double ended shear beam |
Rated Load: | 30t | Sensitivity: | 2.0000±0.002mV/V |
Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
수많은 연구와 개발을 통해 닝보 산트웰 수출입유한공사(Ningbo Santwell Import & Export Co., Ltd.) 는 HM9B QS 30톤 합금강 아날로그 더블 시어 빔 로드셀을 성공적으로 선보였습니다. 이 로드셀은 **트럭 계량기 및 대형 차량용 저울(Weightbridge)**에 최적화된 고성능 센서로, 탁월한 내구성과 안정된 측정 정확도를 자랑합니다. 시장 출시 이후, 본 제품은 세련된 외관과 우수한 성능으로 고객들로부터 높은 신뢰와 호평을 받고 있습니다.
Having been through countless days and nights,Ningbo Santwell Import & Export Co., Ltd has successfully developed Brand Hm9b QS 30 ton alloy steel analog weight sensor for trucks double shear beam weightbridge load cell. It is bound to catch people’s eyeballs in various fields. After Brand Hm9b QS 30 ton alloy steel analog weight sensor for trucks double shear beam weightbridge load cell launching into the market, we have gained a lot of support and praise. Most customers think that this kind of products are in line with their expectations in terms of appearance and performance. Ningbo Santwell Import & Export Co., Ltd always adhere to the principle of ‘creating values for customers and bringing benefits to stakeholders’. In the process of development, we highly focus on the quality and ensure no flawless product delivered to customers.
Model Number: | QS | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | SantWell |
Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
Output: | Resistance strain | Description: | Double ended shear beam |
Rated Load: | 20t 30t 40t | Sensitivity: | 2.0000±0.002mV/V |
Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
Model Number: | QS-(M) | Place of Origin: | Zhejiang, China |
Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
Theory: | Resistance Sensor | Output: | Analog SENSOR |
Rated Load: | 10t-50t | Sensitivity: | 2.0000±0.002mv/v |
Total Error: | ±0.03%F.S | Creep(30 minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
State-of-the-art technologies introduced and upgraded for the more efficient and stable manufacturing of the product. It functions perfectly in the application scenario(s) of Force Sensors & Load Cells. High-quality Tank Scales load cell 20 ton Alloy Steel Classic Design Dry Mortar weight sensor load cell QS-KL rely on strong research and development capabilities and a good brand image. Ningbo Santwell Import & Export Co., Ltd adhere to the corporate spirit of ‘pragmatism & innovation’ and aim to create benefits for our stakeholders. Driven by the fierce competition in the market, Ningbo Santwell Import & Export Co., Ltd hold a firm belief that we must focus on R&D and develop new technologies to adapt to the market trends.
Model Number: | QS-KL | Place of Origin: | Zhejiang, China |
Brand Name: | Santwell | Usage: | PRESSURE SENSOR |
Theory: | Resistance Sensor | Output: | Analog SENSOR |
Rated Load: | 3t~6t | Sensitivity: | 2.0000±0.002mv/v |
Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
Model Number: | QS-F | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
Usage: | truck scale, PRESSURE SENSOR | Theory: | resistance strain, Resistance Sensor |
Output: | 1000000d | Description: | double ended beam load cell |
Sensitivity: | 1000000d | Temperature range,operating: | (-30~+70)℃ |
Construction: | Alloy Steel | Rated Load: | 10/20/30 T |
Safe Overload: | 150%F.S | Protection Class: | IP67 & IP68 |
Output Impedance: | 700±5Ω | Communication Interface: | RS485 |
Model Number: | QS-J | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | santwell |
Usage: | truck scale | Theory: | resistan |
Output: | Resistance strain | Description: | Double ended shear beam load cell |
Rated Load: | 10t-30t | Sensitivity: | 2.0000±0.002mv/v |
Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd is capable of providing a quality range of Shear beam load cell 2 ton Pressure Plate weight sensor Tank Weigh 6 Ton load cell QS-KL. Technological innovation is the fundamental reason for Ningbo Santwell Import & Export Co., Ltd to achieve sustainable development. Ningbo Santwell Import & Export Co., Ltd always adhere to the principle of ‘creating values for customers and bringing benefits to stakeholders’. In the process of development, we highly focus on the quality and ensure no flawless product delivered to customers.
Model Number: | QS-KL | Place of Origin: | Zhejiang, China |
Brand Name: | santwell | Usage: | PRESSURE SENSOR |
Theory: | Resistance Sensor | Output: | Analog SENSOR |
Rated Load: | 3t~6t | Sensitivity: | 2.0000±0.002mv/v |
Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd has a number of elite teams in management, design, R&D, and production. Our product can be tailored to suit you perfectly. Under the leadership of our company’s board of directors, Ningbo Santwell Import & Export Co., Ltd have constantly upgraded our technologies and introduced high-end machines to continuously drive the market trend and improve product quality so as to satisfy every customer. Our aim is to become one of the most trustworthy enterprises in the market.
Model Number: | QS-KX | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | santwell |
Usage: | truck scale | Theory: | resistan |
Output: | Resistance strain | Description: | Double ended shear beam load cell |
Rated Load: | 10t-30t | Sensitivity: | 2.0000±0.002mv/v |
Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
As one of the most popular products, QS-MF 50 ton load cellweighbridge prices of weight sensor trucks scale Double ended shear beam load cell wins increasing popularity. Force Sensors & Load Cells has passed a series of international quality assurance system and product safety certification . We regard QS-MF 50 ton load cellweighbridge prices of weight sensor trucks scale Double ended shear beam load cell product features as its core competitiveness. Adopting high-quality raw materials purchased from reliable suppliers,Santwell has the guaranteed quality and advantages of Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells. Moreover, it has a look designed by our creative designers, making it highly attractive in its appearance.
Model Number: | QS-MF | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | santwell |
Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
Output: | Resistance strain | Description: | double ended shear beam |
Rated Load: | 50t | Sensitivity: | 2.0000±0.002mV/V |
Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
Model Number: | QS-N | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | SantWell |
Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
Output: | Resistance strain | Description: | double ended shear beam |
Rated Load: | 10t 20t 30t 40t | Sensitivity: | 2.0000±0.002mV/V |
Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd is reckoned for manufacturing and supplying QS-R IP67 Water Proof 5 -10 Ton Truck Railway Blending Weight Sensor Half Bridge Load Cell For Digital Scale that is manufactured using supreme quality materials. Based on scientific strategic decision-making, driven by strong operating capabilities, and driven by technology and R&D capabilities, the products developed and manufactured have clear positioning and goals. Get in touch with us – call, fill in our online form or connect via live chat, we are always happy to help.
Model Number: | QS-R | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
Output: | Resistance strain | Description: | Double Ended Shear Beam |
Rated Load: | 10T | Sensitivity: | 2.0000±0.002mv/v |
Total Error: | ±0.03%F.S | Creep(30 minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
In the fierce market competition, Ningbo Santwell Import & Export Co., Ltd has grown continuously. We invest in R&D to find better solutions in the Force Sensors & Load Cells industry. We offer buyer Warehouse Measurement 75 Klb 24 V 2Cr14Ni Double Ended shear beam load cell QS-V that they need at prices that fit their pocket. Relying on our excellent products and sensible marketing strategy,Ningbo Santwell Import & Export Co., Ltd hold a firm belief that we will take a large market share in the future and benefit our stakeholders as well.
Model Number: | QS-S | Type: | Load Cell |
Place of Origin: | Zhejiang, China | Brand Name: | SantWell |
Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
Output: | Resistance strain | Description: | double ended shear beam |
Rated Load: | 10t 20t 30t 40t | Sensitivity: | 2.0000±0.002mV/V |
Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
