ZM3DW-SF 3 axis load cell
Model ZM3DW-SF has 3 independent axes in a small package size. Capacities available are from 1kg — 100kg. Product is made from aluminum alloy so it is very light weight.
ZHIMIN’s 3-axis load cell measures forces simultaneously in 3 mutually perpendicular axes: X, Y, and Z – positive and negative. Each axis provides a unique mV/V output and requires no mathematical manipulation. The 3-axis load cell is built to minimize eccentric loading effects and crosstalk between axes.
The ZM3DW-SF 3-axis load cell is ideally suited to many industrial and scientific applications, such as aerospace, robotics, automotive and medical research (orthopedics and bio-mechanical). The load cell is provided in various capacity ranges and sizes with each of the three axes providing the same capacity.
We providing a custom design if warranted for varying capacities (between X, Y, and Z), higher temperature capability, or OEM/private labeling if needed.
| PARAMETER | VALUE | UNIT |
| Material | Alloy Aluminum | |
| Capacity | 5, 10, 20, 30, 50, 100 | KG |
| Sensitivity X-Axis | 0.5-1.0 | mV/V |
| Sensitivity Y-Axis | 0.5-1.0 | mV/V |
| Sensitivity Z-Axis | 0.5-1.0 | mV/V |
| Zero balance | 1 | ±% of rated output |
| Input resistance X,Y-Axis | 700±5 | Ohms |
| Output resistance X,Y-Axis | 700±5 | Ohms |
| Input resistance Z-Axis | 350±5 | Ohms |
| Output resistance Z-Axis | 350±5 | Ohms |
| Insulation resistance | 5000 | Mega-Ohms |
| Accuracy | 1 | ±% of rated output |
| Non linearity | 0.2 | ±% of rated output |
| Hysteresis | 0.05 | ±% of rated output |
| Temperature effect on min. dead load output | 0.0026 | ±% of rated output/℃ |
| Temperature effect on sensitivity | 0.0015 | ±% of rated output/℃ |
| Creep error (30 minutes) | 0.03 | ±% of rated output |
| Crosstalk from X to Y | 1 | ±% of rated output |
| Crosstalk from Y to X | 1 | ±% of rated output |
| Crosstalk from Z to X/Y | 1 | ±% of rated output |
| Crosstalk from X/Y to Z | 2 | % of R.C |
| Safe overload | 150 | % of R.C |
| Ultimate overload | 300 | % of R.C |
| Excitation, recommended | 10 | Vdc |
| Compensated temperature range | -10 to +40 | ℃ |
| Operating temperature range | -20 to +60 | ℃ |
