SOPMH-103 Factory Price Micro Miniature Load Cell Tension Sensor Pull Rod Pressure Weight Sensor for Automation Industry
Micro Miniature Load Cell Tension Sensor Pull Rod Pressure Weight Sensor 60kg 100kg 200kg 300kg 500kg
Product Description
◆Automotive ,medical ,robot ,electric ,mechanical equipment ,automation equipment ,ETC .
◆Force measurement in small space installation ,such as feeling tester for keyboard switch ,compression force measurement for hot and cold lamination machine ,and grasping force measurement for robotic hands .
Product Features
◆Capacity ：5~500kg
◆Material: stainless steel
◆Defend grade: IP67
◆Low profile and compact structure
Specification
|
Material
|
Stainless Steel
|
|
Capacities (Kgs.)
|
1,3, 5,10, 20, 30, 50, 60, 100, 200, 300, 500
|
|
Rated Output
|
1.0-1.5 ±10% mV/V
|
|
Hysteresis
|
< ± 0.1 % FSO
|
|
Creep (30 minutes)
|
< ± 0.2 % FSO
|
|
Iutput Resistance
|
400 ± 10 Ohms
|
|
Output Resistance
|
350 ± 3 Ohms
|
|
Maximum Overload
|
200%
|
|
Non — Linearity
|
< ± 0.3 % FSO
|
|
Non-Repeatability
|
< ± 0.1 % FSO
|
