Using quality-guaranteed raw materials, high-end technologies, and modern machines, we ensure Weight Scale Module Load Cell Beam Sensor 1000kg 2000kg Weight Transmitter Module SQC-(M) is made perfectly. It has many great features . Moreover,Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells is designed to keep close up with the latest trend and have a unique look.
Shipping: Support Sea freight · Land freight
Customization: Customized logo (Min. Order: 100 Pieces),Customized packaging (Min. Order: 100 Pieces),Graphic customization (Min. Order: 100 Pieces)
Technical Parameter
| Rated Load | 10~40t |
| Sensitivity | 2.0000±0.002mV/V |
| Total Error | ±0.02%F.S |
| Creep(30minutes) | ±0.02%F.S |
| Recommended Excitation Voltage | 5V~18V(AC or DC) |
| Maximum Excitation Voltage | 24V(AC or DC) |
| Zero Balance | ±1%F.S |
| Input Impedance | 380±10Ω |
| Output Impedance | 350±5Ω |
| Insulation Impedance | ≥5000MΩ |
| Safe Overload | 150%F.S |
| Ultimate Overload | 200%F.S |
| Operating Temperature Range | (-30~+70)℃ |
| Compensated Temperature Range | (-20~+60)℃ |
| Temperature Effect On Load | ±0.02%F.S/10℃ |
| Temperature Effect On Zero | ±0.02%F.S/10℃ |
| Construction | Alloy Steel/Aluminum |
| Protection Class | IP67&IP68 |
| Citation | GB/T7551-2008/OIML R60 |
| Mode of Connection | Input+E:Red Input-E:Black Output+S:Green Output-S:White |
