WeighIng Digital Indicator Weigh Waterproof With Printer LP7512 OIML 6-digit 20mm LED or 25mm LCD with backlight creation relies on mature R&D technology and precise market positioning, as well as years of painstaking research.Moreover,customized product is also offered to meet specific requirements of customers.
Rated Load : >300kg
Accuracy : 30000D
Type : weighing indicator, Floor Scale, Truck Scale, Bench Scale, Mechanical Scale
Shipping: Support Sea freight · Land freight
Technical Parameter
| Display | 6-digit 20mm LED or 25mm LCD with backlight |
| Accuracy class | OIML III |
| AD convert |
∑-Δ, 24bit
|
| Input voltage | -10mV ~ 19.5mV |
| Resolution |
display15000, internal code 1000000
|
| Minimum resolution |
1μV/e
|
| Excitation voltage | DC5V |
| Load cell interface | 4-wire(optional:6-wire) |
| Drive capability | 1-4 350Ω analog load cell(s) |
| Power supply |
AC110/240V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery
|
| Work environment | -10ºC ~ +40ºC, ≤85%RH |
| Battery enduring life | 35 hours for continuously use(with 4 350Ω analog load cells) |
Options
| Second display interface | serial RS232 |
| Communication interface | RS232/RS485, baud rate 600~9,600(optional) |
| Printing interface | shared with serial interface, can be connected to serial printer(optional built-in/desktop/thermal printer) |
| Extensible interface | MODBUS-RTU/TCP, Profibus-dp, USB, Ethernet,RF wireless module |
Application for
High precision bench scale, floor scale, waterproof benchscale, hopper scale, pet scale, load cells, etc
