유연한 저울 설계를 가능하게 하여 업계 표준을 세운, HBK의 가장 범용적인 싱글 포인트 로드셀

• 1 kg부터 200 kg까지 폭넓은 정격 용량 범위 제공

• C3MR, C6MR 및 NTEP 5000 III S 정확도 등급으로 정밀한 계량 보장

• LCMC, K-Mat 및 IO-Link 옵션 제공으로 다양한 요구 사항에 맞춘 구성 가능

• IO-Link 스마트 기능 지원: 데이터 전처리, 자가 모니터링, 경고 기능 제공
  → IO-Link로 강화된 스마트 센서가 어떻게 효율성을 향상시키는지 확인해 보세요

• NEW: 업계에서 널리 알려진 이 로드셀이 이제 지능형 IO-Link가 통합된 SP4Mi 버전으로 출시되었습니다

• NEW: LCMC 측정 체인 버전 제공:

  • 스마트 옵션(IO-Link)

  • 디지털 옵션(CANopen 또는 RS-485)

  • 아날로그 옵션(4~20 mA 또는 0~10 V)

• Aluminum alloy,surface anodized and anticorrosion;
• Recommend max platform: 400×500mm;
• Suitable for electronic scale and other weighing equipment with small platform

Very low corner load error
Good cost-benefit ratio
Available with 05 % accuracy and in a legal-for-trade version
Use in hazardous zone with protection class Ex ia IIC T4 Gb / Ex ia IIIC T125 °C Da or protection class
Ex nA IIC T4 Gc / Ex tc IIIC T125 °C Dc
ATEX and IECEx certification
Optimized by exact calibration for parallel circuits
Six-wire circuitry
100 % Stainless steel

It is suitable for measuring force in various small spaces, and is widely used in industrial R & D and other fields of measurement and control;
Can replace traditional scales and platform scale adjustment feet;
Patent products, counterfeiting will be investigated.

Material: stainless steel, High-quality alloy steel
definition: Low height Easy to install

Suitable for ultra-trace testing, medical testing, dispensing volume testing, electronic scales, counting scales, electronic balances and industrial weighing systems

Widely used in process weighing systems in industries such as stainless steel waterproof scales, chemical waterproof pharmaceuticals, etc.

Material: stainless steel, High overall sensitivity
definition: Good stability Four corner deviations have been compensated

A801 Load Cell are well-crafted, beautiful in appearance, and have both excellent performance and excellent quality. Once they are on the market, they have quickly been loved and sought after by the majority of customers.

Высокопроизводительный одноточечный тензодатчик — оптимизирован для сверхбыстрого взвешивания

• Благодаря высокой жёсткости корпуса и собственной частоте вибраций обеспечивает очень быстрое взвешивание

• Номинальная грузоподъёмность: 3–40 кг

• Класс точности: C3MR и NTEP 3000 III S, надёжная и стабильная работа

• Идеален для динамических промышленных приложений

• НОВОЕ: версия измерительной цепи LCMC – выбор опций: смарт (IO-Link), цифровая (CANopen или RS-485), аналоговая (4–20 mA или 0–10 V)

Single point load cell is widely used for weighing scale or pricing scale. Single point load cell is suited to use in flat and low space, with parallel beam structure, good stability, good output symmetry, high accuracy, low temperature drift and overload protection.

A803 Load Cell are well-crafted, beautiful in appearance, and have both excellent performance and excellent quality. Once they are on the market, they have quickly been loved and sought after by the majority of customers.

• Compact design supports legal-for-trade weighing for large scales, even in harsh environments

• C3MR accuracy class ensures precise weighing across the 50 kg – 300 kg range

• Mountable with four fixing screws and supports platforms up to 600 × 500 mm

• IP67 protection rating, with optional explosion-proof version available

• NEW: Available with LCMC measurement chain – smart option (IO-Link), digital option (CANopen or RS-485), and analog option (4–20 mA / 0–10 V)

Widely used in process weighing systems in industries such as electronic scales, electronic balance, etc.

Material: aluminum alloy High overall sensitivity
definition: Good stability Four corner deviations have been compensated
