Technical parameters
| Technical Parameters | |
|---|---|
| 1. | Range / Capacity: 10, 20, 50, 100, 200, 500kg, 1, 2, 3t |
| 2. | Sensitivity: 2.0 ± 0.1mV/V |
| 3. | Combined Accuracy: 0.1%FS |
| 4. | Non-linearity: 0.05%FS |
| 5. | Excitation Voltage: 5-12VDC |
| 6. | Protection Class: IP66 |
| 7. | Operating Temperature: -20°C ~ 70°C |
| 8. | Input Resistance: 735 ± 35 Ω |
| 9. | Output Resistance: 700 ± 35 Ω |
| 10. | Overload Protection: 120%FS |
| 11. | Cable: Ø5 × 2000mm |
| 12. | Material: Stainless Steel |
Dimensions
Buy a tension and compression column load cell online with optional capacities ranging from 1 kg, 5 kg, 10 kg, 20 kg, 50 kg, 100 kg up to 2 tons. This miniature column-type load cell accurately measures both tensile and compressive forces, ideal for use in testing machines, industrial automation, process control, and weighing systems.
| Model: | NF402 |
| Category： | Column Load Cells |
| Capacity: | 10,20,30,50,500,100,200,300,500N |
| Rated Output: | 2.0±10%mV/V |
| Material: | Stainless steel |
| Model: | NF402B |
| Capacity: | 20,50,100,200,300,500N |
| Rated Output: | 2.0±10%mV/V |
| Material: | Stainless steel |
| Protection Class: | IP65 |
Product description:
Capacity ：0~50kg
Stainless steel
High stability
Can be installed in small spaces
Stable anti-interference signal
Compared with traditional column sensor, this structure achieve relatively high accuracy in terms of linearity, anti- side, torsional resistance, and azimuth error
Product description:
Capacity ：0~200kg
Stainless steel
High stability
Can be installed in small spaces
Stable anti-interference signal
Compared with traditional column sensor, this structure achieve relatively high accuracy in terms of linearity, anti- side, torsional resistance, and azimuth error.
Widely used in auto press assembly, automated assembly, 3C product testing;
New energy product assembly, medical testing, robot, mold assembly and other industrial test, measurement and systems.
Material: stainless steel, Aluminum alloy
Size: Overload Protection High precision
Product description:◆Capacity ：0~200N ◆ Stainless steel ◆High stability ◆ Can be installed in small spaces ◆ Stable anti-interference signal ◆ Compared with traditional column sensor, this structure achieve relatively high accuracy in terms of linearity, anti- side, torsional resistance, and azimuth error. ◆Widely used in automotive pressing, automatic assembly, 3C product testing, new energy product assembly, medical testing, machines Robot field, mold assembly and other industrial testing,motorizing equipment and testing field
