Model: CZL700C
Use:
Structural diagram
parameter
| Rated load | 50kg |
| Zero output | ±0.3 mV/V |
| Output sensitivity | 0.8±0.2 mV/V |
| Nonlinear | 0.2% FS |
| lagging | 0.2% FS |
| Repeatability | 0.1% FS |
| Creep | 0.2% FS/3min |
| Output (input) impedance | 1000±10Ω |
| Service temperature | -10℃ ~ +40 ℃ |
| Zero temperature effect | ±0.2% FS/10℃ |
| Sensitivity temperature effect | ±0.2% FS/10℃ |
| Insulation resistance | ≥2000MΩ |
| Working temperature | -10℃ ~ +40 ℃ |
| Excitation voltage | 5VDC ~ 10VDC |
| Ultimate Overload | 150% FS |
| Material Science | Manganese Steel |
| Protection level | IP65 |
| Overall dimension of sensor | 48*22*2.5 |
