TAL230A Miniature load cell
INTRODUCTION:
Model 13 (compression only) subminiature load cell is designed to measure load ranges from 150 g to 1000 lb. With subminiature dimensions, including diameters from 0.38 in to 0.75 in and heights of 0.13 in to 0.25 in, these units are easily incorporated into systems having limited space. Model 13 combines high frequency response and low deflection to achieve a combined non-linearity and hysteresis of 0.25 % to 0.5 % full scale. A balance module is included in the load cell’s lead wire cable for temperature compensation and should not be removed.
It is widely used in key force test and various key switch test of various 3C products such as computers;
Various insertion force tests, medical tests, and other industrial tests have high dynamic response frequencies.
Material: stainless steel
Size: S type, With overload protection function
Эластомер сенсора изготовлен из алюминиевого сплава, герметизирован клеем, поверхность обработана прозрачным анодированием. Степень защиты достигает IP65.
Widely used in auto press assembly, automated assembly, 3C product testing;New energy product assembly, medical testing, robotics, mold assembly;
And other industrial test, measurement and control systems.
Material: 17-4PH stainless steel
Size: High speed, low deflection
Model 11 (tension/compression) subminiature load cell is designed to measure load ranges from 150 g to 1000 lb. With subminiature dimensions, including diameters from .50 in to 0.75 in and height of 0.38 in, these units are easily incorporated into systems having limited space. The model achieves a non-linearity and hysteresis of 0.5 % full scale respectively and a frequency response of up to 58 kHz. A balance module is included in the load cell’s lead wire cable for zero balance, and should not be removed.
Used in injection molding and extrusion manufacturing processes;
Automobile pressing, 3C product testing, new energy product assembly,
Medical testing, robotics, and other industrial test, measurement, and control systems.
Эластомер сенсора изготовлен из алюминиевого сплава, герметизирован клеем, поверхность обработана прозрачным анодированием. Степень защиты достигает IP65.
Used in auto press assembly, automated assembly, 3C product testing New energy product assembly, medical testing, robotics, etc.
Product Numbers:TAS501M
Product description:
Capacity ： 0.5~50kg
Material: alloy steel or stainless steel
Type: S type
Defend grade: IP67.
Application: electronic crane scale, hopper scale,mechanical conversion scale and other electronic weighing devices.
Widely used in auto press assembly, automated assembly, 3C product testing;New energy product assembly, medical testing, robotics;
Mold assembly and other industrial test, measurement and control systems, etc.
Material: stainless steel, High temperature performance can be determine, Customizable high temperature performance
Size: Thin design, Large range
Widely used in welding force test, tension test, auto press assembly, automated assembly, 3C product test,New energy product assembly, medical testing, robotics, mold assembly, and other industrial test, measurement, and control systems;High dynamic response frequency.
Material: stainless steel
Size: S type Low height
It is widely used in key force test and various key switch test of various 3C products such as computers;
Various insertion force tests, medical tests, and other industrial tests have high dynamic response frequencies.
Material: stainless steel
Size: S type, With overload protection function
