GBS800 Truck scales Bridge Ball type load cell
Bridge Type Load Cells also called Cup & Ball Type Shear Beam Load Cells, in order to meet the changing demands of our clients, we have been engaged in offering a quality range of this kind of load cells. These loadcell with steel ball centre positioning design. They have high accuracy and side load tolerance, stable performance. This Unique design suitable for multiform environments and are used for electronic truck scale, rail scale, ground scale and other weighing system.
What is specifications of GBS800 Load cell?
| Specification | |
| Rated load | 3,5,10,20,30,50,100,200,300,500,1000KN |
| Precision | 0.03~0.1%F.S |
| Rated output | 2.0mV/V |
| Creep | ±0.03% F·S/30min |
| Zero output | ±1% F·S |
| Temperature effect on zero | ±0.03% F·S/10℃ |
| Temperature effect on output | ±0.03% F·S/10℃ |
| Operating temp.range | -20~+65℃ |
| Input resistance | 380±10Ω/750±15Ω |
| Output resistance | 350±3Ω/700±5Ω |
| Insulation resistance | ≥5000MΩ(50VDC) |
| Safe Overload | 150% F·S |
| Bridge voltage | 5~15VDC |
What is dimension of GBS800 Load cell?
What is details of GSBS800 Load cell?
