Models
FA510
Features
| Product Name: | Weighing Sensor Shear Beam Load Cell For Vessel Scale | Capacity: | 500kg |
|---|---|---|---|
| Sensitivity: | 2.0±0.05%mV/V | Non-linearity: | ≤0.018%F.S. |
| Repeatability: | ≤0.018%F.S. | Material: | Stainless Steel |
| Zero Balance: | ±0.02mV/V | Creep(30min): | ≤0.0166%F.S |
Dimensions
Specifications
| Item | Unit | Specification |
|---|---|---|
| Product name | – | 500kg Weighing Sensor Shear Beam Load Cell for Vessel Scale |
| Capacity | kg | 500 |
| Sensitivity (Rated output) | mV/V | 2.0 ±0.05% |
| Zero balance | mV/V | ±0.02 |
| Creep (30 min) | %F.S. | ≤0.0166 |
| Non-linearity | %F.S. | ≤0.018 |
| Hysteresis | %F.S. | ≤0.017 |
| Repeatability | %F.S. | ≤0.018 |
| Input impedance | Ω | 390 ±5 |
| Output impedance | Ω | 350 ±5 |
| Temp. effect on output | %F.S./10 ℃ | 0.008 |
| Temp. effect on zero | %F.S./10 ℃ | 0.0125 |
| Insulation resistance | MΩ/100V (DC) | ≥5000 |
| Recommended excitation | V | 5~15 |
| Maximum excitation | V | 20 |
| Compensated temp range | ℃ | -10~40 |
| Operating temp range | ℃ | -30~70 |
| Safe overload | %F.S. | 150 |
| Ultimate overload | %F.S. | 200 |
| Cable size | – | ⌀5.4×1.5m |
