WL-151 Precision Load Cell 15kg Capacity with ±0.1% Accuracy and IP66 Protection
|
Capacity:
|
15kg
|
Combined Error:
|
0.1%F.S.
|
|
Non-linearity:
|
0.02%F.S.
|
Repeatability:
|
0.02%F.S.
|
|
Rated Output:
|
1.0mV/V
|
Zero Balance:
|
±2%F.S.
|
|
Insulation Resistance:
|
>5000MΩ/100VDC
|
Recommended Excitation:
|
3-12VDC
|
|
Material:
|
Stainless Steel
|
Safe Overload:
|
120%F.S
|
|
Protection Class:
|
IP66 (Customizable)
|
Operation Temp.:
|
-10~80°C
|
|
Cable Size:
|
Ф3.0x1m
|
WL-151 Precision Load Cell: 15kg Capacity with ±0.1% Accuracy and IP66 Protection
Features & Applications
Key Features:
-
15kg capacity load cell
-
±0.1% F.S. accuracy
-
1.0mV/V rated output
-
IP66 protection grade
-
120% safe overload
-
3-15V excitation voltage
-
Applications:
-
Precision industrial scales
-
Laboratory force measurement
-
Small platform weighing
-
Automated production lines
-
Quality control systems
Our Commitment:
At Brans, we pride ourselves on delivering tailored solutions that precisely match our clients’ unique requirements. Recognizing that every application has distinct challenges, we offer customizable single point load cell configurations to ensure optimal performance for your specific needs.
Custom Solutions Available:
• Application-specific adaptations
• Modified specifications upon request
• Engineering support for specialized requirements
Specifications:
| Capacity | 15kg |
|---|---|
| Combined Error | 0.1%F.S. |
| Non-linearity | 0.02%F.S. |
| Repeatability | 0.02%F.S.. |
| Rated Output | 1.0F.S. |
| Zero Balance | ±1%F.S. |
| Insulation Resistance | >5000MΩ/100VDC |
| Recommended Excitation | 3-12VDC |
| Material | Stainless Steel |
| Operation temp | -10~80°C |
| Safe overload | 120%F.S. |
| IP class | IP66 (Customizable) |
| Cable size | Ф3x1m |
Dimension(MM):
Load Direction:
