KWT1D78 series single-axis force sensor is a high-accuracy and multi-function force sensor improved on KWT1D78 (gland), Plug-in design allows easy connection and disconnection between cables and sensors.
| Model Number: | SB-(M)-D | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 0.5-20t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
| Model Number: | SB-(M)-D | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 0.5-20t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
1.Using high-quality sensors, the weighing accuracy is high.
2.Unique structure, and can be conveniently installed on various tanks.
3.Support bolts to prevent equipment from overturning.
4.High-quality alloy steel .
5.Simple and fast installation.
6.Convenient maintenance, saving downtime and maintenance time.
7.Widely used in platform scales, truck scales, track weighbridges, silos, storage tanks, tank scales and other weighing equipment. Or it can be used in weighing applications of large tanks, silo scales, reaction kettles, hoppers and vertical tanks.
| Model Number: | SB-(M)-S | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Description: | SANTWELL | Rated Load: | 0.5-20t |
| Sensitivity: | 2.0000±0.002mV/V | Total Error: | ±0.02%F.S |
| Creep(30minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V~18V(AC or DC) |
| Maximum Excitation Voltage: | 24V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | 150%F.S |
| Utimate Overload: | 200%F.S |
| Model Number: | SB-(M)-S | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Description: | SANTWELL | Rated Load: | 0.5-20t |
| Sensitivity: | 2.0000±0.002mV/V | Total Error: | ±0.02%F.S |
| Creep(30minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V~18V(AC or DC) |
| Maximum Excitation Voltage: | 24V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | 150%F.S |
| Utimate Overload: | 200%F.S |
