GSI201 Digital truck scale weighbridge load cell indicator
Introduction
Weighing indicator GSI-201 adopts high precision ∑-Δ A/D conversion technology, widely applied in electronic floor scale、electronic truck scale and so on alike static weighing system equipped with 1~8 load cell.
Feature:
◆ Compatible with all functions of model GSI-201;
◆ ∑-Δ high precision A/D conversion method, able to process input signal from -16mV to 18mV
◆ Good consistency, no need to re-calibrate a scale if change the former indicator, high precision
◆ DC power socket with anti-connect and anti-short circuit protection;
◆ With strong anti-disturbance function
Standard Function
◆ AC/DC power supply, standard chargeable battery
◆ 7-bits 0.8 inch LED display, 3-level battery indications
◆ Able to setup zero-tracking range, zero(auto/manual) range
◆ With 2-point calibration correction function, 2 compensation calibration methods
◆ Able to save 1001 weighing records, 1000 truck records consisting of truck ID and corresponding tare weight, 201 records of goods
◆ Able to print across and upright weighing bill
◆ Able to print different statistical reports
◆ Standard RS232 communication interface (RS422/RS485 optional)
◆ Standard parallel print interface
◆ Able to connect assigned thermal printer
Technical Parameter
◆ A/D conversion code: 1 million code
◆ Load cell excitation: DC 5V
◆ Max. connection number of load cell: 8 at 350 ohm/16 at 700 ohm
◆ Load cell connection mode: 6 wire, auto compensation for long distance
◆ Division: 1/2/5/10/20/50/100 optional
◆ Clock: real clock without effect when power off
◆ Transmission: current loop/RS 232 signal
◆ Baud rate: 600
◆ Transmission distance: ≤30 meters
◆ Serial communication: interface
◆ Transimission method: RS232/RS422(optional)/RS485(optional)
◆ Baud rate: 600/1200/2400/4800/9600(optional)
◆ Transmission distance:RS232: ≤30 meters; RS422/RS485: ≤1200 meters Print interface
◆ Standard parallel output interface
◆ Built-in micro-printer (GSI201+P)
◆ Data storage:1000 truck records consisting of truck ID and corresponding tare weight 201cargo ID.1001 weighting records
◆ Power supply: AC 220V(-15%-+10%); 50Hz(-2%-+2%)
DC 6V/10Ah External battery rechargeable
