Technical Parameter
| Product model | X-GMPS-1M |
| Power supply | 12V-28VDC |
| Operating temperature | -10℃-70℃ |
| Communication | RS485 |
| Bus type | Modbus RTU |
| Baud rate | Default 115200,settable |
| Support stitching Max.Qty | Can be spliced, with a maximum of 32 splices |
| Data update time | N*30 ms(N represents the number of channels) |
| Communication trigger mode | Default command mode, switchable with automatic upload mode |
| Sampling value | 18 Digits |
| Resolution | 1μm |
| Zero function | By instructions |
| Connection | 9pin connector |
Dimension & Capacity
