Model AL-JP is a high output load cell (30 mV/V minimum). These semiconductor strain gage load cells are engineered to measure loads from 500 lb to 2000 lb. The tension/compression Model AL-JP is designed with female threads. It provides high performance in non-linearity, hysteresis, and repeatability. Low mechanical deflection allows for better response capability.

The pedal pressure sensor mounts directly to the brake pedal with its own mounting clamp. Load applied up to 1/2 inch off center, produces less than a 0.5% error. Standard capacity is 300 lbs. This load cell, which is used for brake pedal force measurements by the automotive industry, finds many production applications. It adapts to any of the pedal or bar operated devices used in all production facilities.

TJL-12 ice detection load cell has good weather resistance and sealing stable performance. The main supply of high voltage power transmission and transformation engineering, used for power transmission and transformation line ice-covered online monitoring system tension monitoring and measurement, and according to customer requirements to add analog transmitter or digital module.

This membrane load cell is made of stainless steel with a strong anti-eccentric load and double seals. Suitable for force detection in various harsh environments. These load cell types have a compact design in the measuring direction, ensuring ease of installation. We also provide custom-made fabrication to meet the specific requirements of our customers.

Low height, easy to install, strong anti-eccentric load capacity, good sealing. Suitable for braking force detection of vehicles.

용량：90kN

재질 : Stainless steel

타입 : PIN

보호등급 : IP69K

Model AL-SC is high-output load cell. These semiconductor strain gage load cells are engineered to measure loads from 500 lb to 2000 lb. The tension/compression Model AL-SC is designed with female threads. It provides high performance in non-linearity, hysteresis, and repeatability. Low mechanical deflection allows for better response capability.
