Features:
- Available Capacity: 3kg, 5kg
- Available in Half Bridge configuration (4 sensors)
- Alloy Steel Construction
Application:
- Kitchen scale
- Pricing scale
- Small weighing scale
- Force test equipment
Dimensions
Specifications
| Capacity | 3kg,5kg |
| Accuracy | 0.15%F·S |
| Zero output | ±0.5mv/V |
| Rated output | 1.0 ± 0.15mv/V
1.5± 0.15 mv/V |
| Creep | ±0.05 %F·S/3min |
| Non-linearity | ±0.1 %F·S |
| hysteresis error | ±0.05 %F·S |
| Repeatability | ±0.05 %F·S |
| Temp. effect on sensitivity | 0.1%F·S/10℃ |
| Temp. effect on zero | 0.1%F·S/10℃ |
| Insulation resistance | ≥ 2000 MΩ |
| Use temp. | -10-+40℃ |
| Excitation voltage | 5～ 10 VDC |
| Ultimate overload | 150%F·S |
| Load cell material | Alloy steel |
| Connecting cable | Φ0.8x300mm |
