Fx Fy 500N Fz 700N Mx My Mz 18Nm Hard Aluminum Alloy Six Axis Force Sensor FARS82D is a model from FARS82 which belongs to our brand FIBOS FARS-Series, FARS82D can be used to measure six axis force Fx,Fy are both 500N, Fz is 700N, and Mx,My,Mz are all 18Nm, its weight is 0.36kg, it’s heavier than FARS82.

Fx Fy Fz Each 30N Mx My Mz Each 1.5Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS36A is a model from FARS36 which is in six-axis force sensor category. FARS36A can measure 6-axis force Fx,Fy and Fz are 30N, Mx,My and Mz are 1.5Nm, its Diameter is 36mm and Height is 20mm, its weight is 0.04kg.

Fx Fy 200N Fz 400N Mx My Mz 18Nm Hard Aluminum Alloy Six Axis Force Sensor FARS94B belongs to FARS94 which is in Six Axis Force Sensor category of our brand FIBOS FARS-Series, FARS94B could be used to measure 6-axis force that Fx,Fy are both 200N, its Fz is 400N, and Mx,My,Mz are all 18N.m, its Height is 26mm.

Suitable for the measurement of multi-directional forces in robot arms, robots, aircraft, medical technology, shipbuilding, etc.

Suitable for the measurement of multi-directional forces in robot arms, robots, aircraft, medical technology, shipbuilding, etc.

Fx Fy Fz 200N Mx My Mz 8Nm Hard Aluminum Alloy Six Axis Force Sensor FARS82B is a model from FARS82 which belongs to our brand FIBOS FARS-Series, FARS82B can be used to measure six-axis force Fx,Fy,Fz all are same 200N, Mx,My,Mz are same 8Nm, its Diameter is 82mm and Height is 31.5mm, its weight is 0.28kg.

0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensors FARS75A is a model of our brand FIBOS FARS-Series, it belongs to 6-axis force sensor FARS75. FARS75A can be used to measure six-axis force Fx,Fy and Fz are 50N, Mx,My and Mz are all 2Nm, its Diameter is 75mm and Height is 31.5mm, its weight is 0.26kg.

Fx Fy Fz Each 150N Mx My Mz Each 5Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS46B is a model of our brand FIBOS FARS-Series, it belongs to FARS46. FARS46B can be used to measure multi-axis force Fx,Fy and Fz are the same 150N, Mx,My and Mz are all 5Nm, its Diameter is 46mm and Height is 19.4mm, its weight is 0.05kg.

Fibos force sensor multiple range load cell FA704C can measure forces in three vertical axes at the same time. The 3-axis load cell is available in a capacity range from 50N to 5000N for all three axes. The three-dimensional force sensor is based on the strain transducer and adopts the resistance strain transducer principle. The 30mm height of this multi-axis load cell allows it to be used in many situations

XYZ 10,50,100,500kg Or Customized 3 Axis Force Sensor FA730 is a model of our brand FIBOS FA7-Series, 3 Axis Force Sensor FA730 can be used to measure 3 axis force, its X axis,Y axis and Z axis force range are all the same 10kg,50kg,100kg and 500kg or customized capacity, its Creep(30min),Hysteresis and Repeatability all the same ≤0.02%F.S. or can be customized, its Hysteresis ≤0.02%F.S. or can also be customized.

Fx Fy Fz 50N Mx My Mz 2Nm 0.1%F.S. Hard Aluminum Alloy Six Axis Force Sensor FARS82A is a model of our FIBOS FARS-Series, it belongs to FARS82 which is its mother model, FARS82A can be used to measure 6-axis force Fx,Fy,Fz are same 50N, and Mx,My,Mz are same 2Nm, its weight is 0.26kg, it has very similar shape with FARS82.
