Suitable for the measurement of multi-directional forces in robot arms, robots, aircraft, medical technology, shipbuilding, etc.

Fx Fy Fz 200N Mx My Mz 8Nm Hard Aluminum Alloy Six Axis Force Sensor FARS82B is a model from FARS82 which belongs to our brand FIBOS FARS-Series, FARS82B can be used to measure six-axis force Fx,Fy,Fz all are same 200N, Mx,My,Mz are same 8Nm, its Diameter is 82mm and Height is 31.5mm, its weight is 0.28kg.

XYZ 50N 100N 200N 500N 1000N 2000N 5000N IP66 3 Axis Force Sensor FA704 is a model of our brand FIBOS FA7-Series, 3 Axis Force Sensor FA704 can be used to measure 3 axis force, its X axis, Y axis and Z axis force range are all the same 50N,100N,200N,500N,1000N,2000N and 5000N capacity, its Rated output is 1.0mV/V, its Zero Balance range is ±2%F.S..

Fx Fy Fz Each 30N Mx My Mz Each 1.5Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS36A is a model from FARS36 which is in six-axis force sensor category. FARS36A can measure 6-axis force Fx,Fy and Fz are 30N, Mx,My and Mz are 1.5Nm, its Diameter is 36mm and Height is 20mm, its weight is 0.04kg.

XYZ 0.5,1,3,5,10,30kN Or Customized 3 Axis Force Sensor FA731O belongs to FA731, 3 Axis Force Sensor FA731O can be used to measure three-axis force, its X axis,Y axis,Z axis force range all are same 0.5kN,1kN,3kN,5kN,10kN,30kN or customized capacity, its Creep(30min) and Repeatability both ≤0.08%F.S. or can be customized.

Fx Fy Fz 50N Mx My Mz 2Nm 0.1%F.S. Hard Aluminum Alloy Six Axis Force Sensor FARS62A is a model of Six Axis Force Sensor, it belongs to FARS62 in our brand FIBOS FARS-Series, it can be got to measure multiple axis load Fx,Fy,Fz are 50N, Mx,My,Mz are 2Nm, its weight is 0.12kg, its shape makes it also look like FARS62.

Fx Fy 400N Fz 500N Mx My Mz 12Nm Hard Aluminum Alloy Six Axis Force Sensor FARS82C is a model of Six Axis Force Sensor, it belongs to FARS82 in our brand FIBOS FARS-Series, Six Axis Force Sensor FARS82C can measure multi-axis force Fx,Fy are both 400N, Fz is 500N, Mx,My,Mz are all the same 12Nm, its Diameter is 82mm and Height is 33.5mm, its weight is 0.32kg.

Fx Fy 400N Fz 500N Mx My Mz 12Nm IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS75C is a model of our brand FIBOS FARS-Series, it belongs to FARS75. FARS75C can be used to measure 6 axis force Fx and Fy are 400N, Fz is 500N, Mx,My and Mz are 12Nm, its Diameter is 75mm and Height is 33.5mm, its weight is 0.36kg.

Fx Fy Fz Each 50N Mx My Mz Each 2Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS46A is a model of FARS46 which belongs to our brand FIBOS FARS-Series. FARS46A can measure six-axis load Fx,Fy and Fz are 50N, Mx,My and Mz are the same 2Nm, its Diameter is 46mm and Height is 19.4mm, its weight is 0.06kg.

XYZ 50-300kg Stainless Steel 3 Axis Force Sensor FA728 is a model of our brand FIBOS FA7-Series, 3 Axis Force Sensor FA728 can be used to measure 3-axis force, its X axis,Y axis,Z axis force ranges the same from 50kg up to 300kg capacity, its Rated output range is 1.0±10%mV/V, and its Zero Balance range is ±1%mV/V.

Suitable for the measurement of multi-directional forces in robot arms, robots, aircraft, medical technology, shipbuilding, etc.
