Product Features:
This product adopts S-shaped structure, compact structure, easy installation, high precision, high reliability. It can be used for mechatronics scales, packaging scales, sorting scales and belt scales, construction machines, etc.
| Capacity(kg) | A(mm) | B(mm) | C(mm) | D(mm) |
| 1000 | 69 | 69 | 22 | Φ78 |
| 2000 | 76.8 | 76.8 | 32 | Φ85 |
Technical Parameters: Rated
Load: 1000 to 2000kg
Accuracy Class: C3 and C2
Sensitivity: 2.0 ±0.002% mV/V
Nonlinear (with Hysteresis): ±0.05% F.S
Repeatability: ±0.05% F.S
Creep (30 minutes): ±0.05% F.S
Temperature Effect on Zero Point: ±0.05% F.S/10°C
Temperature Effect on Sensitivity: ±0.05% F.S/10°C
Operating Temperature: -30 to +70°C
Temperature Compensation Range: -20 to +60°C
Safe Bearing: 150% F.S
Ultimate Load: 200% F.S
Breaking Load: 300% F.S
Input Resistance: 400 ±20Ω
Output Resistance: 350 ± 2Ω
Insulation Resistance: ≥5000MΩ Zero
Point Balance: ±1% F.S
Recommended Working Voltage: 10V DC
Maximum Working Voltage: 15V DC
Material: Stainless Steel/Alloy Steel
Cable Length:
Protection Level: IP67
Reference Standard: GB/T7551-2008 OIMLR60
Wiring Method: Input
+: Red
Input -: Black
Output + : Green
Output -: White
