Models
B510-50kg, B510-100kg, B510-250kg, B510-0.5t, B510-1t, B510-2t, B510-3t, B510-5t, B510-7.5t, B510-10t
Features
- 용량：50kg~10t
- 재질 : Alloy steel，stainless steel optional
- 타입 : Single-Ended Beam
- 보호등급 : IP67/lP68
- 바닥 저울, 의료용 침대 저울 및 기타 전자 저울 장치에 적합
Dimensions
| Capacity | L | L1 | L2 | L3 | L4 | D1 | D2 | H | H1 | W | W1 | M |
| 50~250kg | 130.0 | 15.8 | 25.4 | 76.2 | 54.2 | 13.0 | 13.5 | 31.8 | 15.8 | 31.8 | 36.8 | M12*1.75 |
| 500~2,000kg | 130.0 | 15.8 | 25.4 | 76.2 | 54.2 | 13.0 | 13.5 | 31.8 | 15.8 | 31.8 | – | M12*1.75 |
| 3,000~5,000kg | 171.5 | 19.1 | 38.1 | 95.3 | 77.2 | 19.5 | 20.6 | 38.1 | 22.0 | 38.1 | – | M18*1.50 |
| 7,500~10,000kg | 222.3 | 25.4 | 50.8 | 120.7 | 101.6 | 26.0 | 26.0 | 50.8 | 25.4 | 50.8 | – | M24*2.00 |
Specifications
