M8T | M8R Compression Load Cell
Features
- Large capacity up to 60000kg
- Alloy steel material
- M8T with screw fixing kit
- M8R with ball cup
- Suitable for weighbridge and other weighing systems
Models
| Part No. | 120255 | 120256 | 120257 | 120258 | 120259 | 120260 | 120261 | 120262 | 120263 |
| M8T | 500kg | 1t | 2t | 3t | 5t | 10t | 20t | 30t | 50t |
| Part No. | 120264 | 120265 | 120266 | 120267 | 120268 | 120269 | 120270 | 120271 | 120272 |
| M8R | 500kg | 1t | 2t | 3t | 5t | 10t | 20t | 30t | 50t |
| Class | C3 | ||||||||
| IP | IP67/IP68 | ||||||||
| Item | Specification |
|---|---|
| Capacity | 500 – 60,000 kg |
| Sensitivity | 2.0 ± 0.001 mV/V |
| Accuracy | C3 |
| Creep (30 min) | ±0.02% F.S. |
| Zero Balance | ±1% F.S. |
| Temperature Effect on Zero (TE Zero) | ±0.02% F.S. / 10℃ |
| Temperature Effect on Span (TE Span) | ±0.02% F.S. / 10℃ |
| Input Resistance | 775 ± 5 Ω |
| Output Resistance | 700 ± 2 Ω |
| Insulation Resistance | ≥ 5,000 MΩ |
| Operating Temperature Range | -30 ~ 70 ℃ |
| Safe Load | 150% F.S. |
| Overload Limitation | 200% F.S. |
| Recommended Excitation | 5 – 18 V |
| Maximum Excitation | 24 V |
| Protection | IP67 | IP68 |
