M20 Single Point Load Cell
M20 Single Point Load Cell, big size and big capacity
Aluminum alloy material
OIML & NTEP approval
Capacity up to 1000Kg
Anodized load cell body
Recommended platforms:
from 600*600mm | 800*800mm
default of 3m Cable dia 5mm
Customized cable available
Models
| Part No. | 120081 | 120082 | 120083 | 120084 | 120085 |
| M20 | 200kg | 300kg | 500kg | 635kg | 1000kg |
| Class | C3 | ||||
| IP | IP65 | ||||
| Item | Specification |
|---|---|
| Capacity | 100 – 1000 kg |
| Sensitivity | 2.0 ± 0.2 mV/V |
| Accuracy | C3 |
| Creep (30 min) | 0.02% FS |
| Zero Balance | ±2% Emax |
| Temperature Effect on Zero (TE Zero) | 0.017% FS / 10℃ |
| Temperature Effect on Span (TE Span) | 0.014% FS / 10℃ |
| Input Resistance | 409 ± 6 Ω |
| Output Resistance | 350 ± 3 Ω |
| Insulation Resistance | ≥ 5000 MΩ |
| Operating Temperature Range | -35 ~ 65 ℃ |
| Safe Load | 150% F.S. |
| Ultimate Overload | 300% F.S. |
| Recommended Excitation | 5 – 12 VDC |
| Protection | IP65 |
