HBTLSF3007T S Type Tension Compression Load Cell Force Sensor for Crane Scales
Key Features:
Small Capacity: Accurately measures weights up to 20-2000 KN
Aluminum alloy or stainless steel construction: We can tailor raw materials to meet customer needs.
IP66/IP67 Protection Rating: The load cell is designed to meet an IP66/IP67 protection rating.
Accuracy: Provides high-precision measurements suitable for applications requiring accurate weight data.
Easy installation.
Usage & Applications:
Hopper scales & silo weighing
Crane scales & overload monitoring
Tension control (e.g., cables, ropes, conveyors)
Machine testing & force measurement
Batching, blending & mixing systems
Belt scales & dynamic weighing
Industrial automation & process control
Material testing machines
Marine/offshore equipment
Aerospace component testing
HBTLSF3007T Customized Options
| 参数 (Parameter) | 可选范围/说明 (Options/Description) |
|---|---|
| 额定载荷 (Rated Load) | 1-200t Higher ranges customizable) |
| 输出灵敏度 (Sensitivity) | 标准范围：2.0mV/V，可调整 (Default 2.0mV/V, adjustable) |
| 电缆长度 (Cable Length) | 标准线长是2米，可定制长度 (Standard 2m, customizable length) |
| 电缆材质 (Cable Material) | PVC/ PUR/耐高温/防水等 (PVC, PUR, High-temp, Waterproof, etc.) |
| 连接方式 (Connection) | 电缆直出/航空插头 (Integrated cable/Quick connector) |
| 防护等级 (IP Rating) | IP65/IP66（防尘防水定制）(Dust/Waterproof customization) |
| 材质 (Material) | 合金钢/不锈钢 (Alloy Steel/Stainless Steel) |
| 安装螺纹 (Thread Type) | 公制/英制螺纹 (Metric/Imperial thread) |
| 工作温度 (Temperature) | -20℃~+65℃ |
Dimension Size:
HBTLSF3007T S Type Tension Compression Load Cell Specifications:
| Parameter | Value/Range/Description |
|---|---|
| Rated Load (kN) | 20，30，50，70，100，150,200，300，500，700，1000,2000 (kN) |
| Comprehensive Precision | 0.02～0.05%F·S |
| Sensitivity | 2.0 mV/V |
| Creep | ±0.05 %F·S/30min |
| Zero Output | ±1 %F·S |
| Temperature Effect On Zero | ±0.02 %F·S/10℃ |
| Temperature Effect On Output | ±0.02 %F·S/10℃ |
| Operating Temperature Range | -20℃～+65℃ |
| Input Resistance | 680±10 Ω |
| Output Resistance | 680±5 Ω |
| Insulation Resistance | >5000 MΩ |
| Safe Load Limit | 150% F·S |
| Bridge Voltag Recommended | 10V DC |
| Material | Alloy Steel |
| Load Cell Wiring | |
| Input+ | Red |
| Input- | Black |
| Output+ | Green |
| Output- | White |
