DYX-306A Single-Ended Beam Load Cell Specifications
Special features
- Aluminum construction
- capacities from 300g to 5kg
- Complies with OIML R60 regulations up to 6000d divisions
- Special silicone rubber potting (IP67)
- Off-center load compensated(OIML R76)
- Applications: platform scale, packaging scale and process weighing systems
Option
- Aligned output, suitable for parallel connection
- Six-wire circuit
- Explosion-proof versions
Dimensions
Notes:
1) Error due to combined effect of non-linearity and hysteresis.
2) Sum of temperature-effect errors complies with OIML R60 and NIST HB44.
3) AL = Applied Load.
