BRG232 Miniature In Line Load Cell
Production Introduction
The Miniature In Line Load Cell is actually a device that transforms a weight signal into a measurable electrical signal output. It is made of aluminum alloy, which is not only chemically stable, but also strong and plastic enough and has stable mechanical properties at certain high or low temperatures. It is equipped with an anti-interference cable and sensitive strain gauges with IP65 protection, making it not only highly applicable but also capable of accurately detecting data every time.
Technical Parameters
| Model | BRG-232 |
| Capacity | 6,10,20,30,40 KG |
| Related output | 2.0± 0.15 MV/V |
| Accuracy class | C3 |
| Maxlmum number of verification intervals | 3000n max |
| Minimum load cell verification intervals | E Max/7500 V min |
| Combined erro | ≤ ±0.02 %RO |
| Creep | 0.016 %RO/ 30min |
| Temperature effect on sensitivity | 0.00167 %RO /℃ |
| Temperature effect on zero | 0.002%RO /℃ |
| Zero balance | ±1.0 %RO |
| Input resistance | 1066± 10Ω |
| Output resistance | 1000± 10Ω |
| Insulation resistance | 5000MΩ (50V) |
| Recommended excitation voltage | 10~ 15V |
| Compensated temperature range | -10 ~+40 ℃ |
| Operating temperature range | -35 ~+80 ℃ |
| Safe overload | 150 %RO |
| Ultimate overload | 200 %RO |
| Load cell material | ALUMINIUM |
| Platform size | 350X350 mm |
| Connecting cable | Φ 4.2X3.5m |
| Protection level | IP65 |
Dimension (mm)
Electrical Connection
Carefully Selected Materials: Aluminum Alloy
The sensor elastomer is made of aluminum alloy; it undergoes sealing treatment (either by sealing or welding), surface nickel plating, making it waterproof, corrosion-resistant, and achieving an IP66 protection rating.
High Stability and High Precision
High cost-performance ratio, meticulous workmanship, safe materials, and excellent craftsmanship. Five-core cable with shielding ensures stable signal, anti-interference, and tensile strength.
Wide Range of Applications
Suitable for electronic price-computing scales, platform scales, electronic guardrails, force measurement in small household appliances and small machinery, etc.
