1.Column Type, hermetically sealed structure, argon-arc welded, good self-centering, fast dynamic response, strong anti-overload capability.
2.Simple to install, easy to use.
3.Suitable for electronic truck scales, railroad scale and big capacity hopper scale, etc.
1. Super strong resistance for anti shock pressure;
2. Operating perfectly under 10m water;
3. Could work under harsh environment i.e. in dusty, sandy or icing environment;
4. Made of alloy steel, with reset function which enable the sensor to bear side impact;
5. Super stability on accuracy during long term operation;
6. User friendly, accuracy will not be affected in case that the product is installed with 5mm center deviation.
1.Made of stainless steel;
2. Suitable for proportioning control system, detecting equipment and other weighing devices.
1.Capacity：1~470t;
2.Material：alloy steel & stainless steel;
3.Protection class：IP68;
4.Application：Axel-load scale，hopper scale，warehouse scale，silo scale.
1. Made of alloy steel or stainless steel
2. Suitable for belt weigher, hopper scale and other weighing devices
3. Good steel performance and high accuracy
1. Made of alloy steel or stainless steel
2. Suitable for belt weigher, hopper scale and other weighing devices
3. Good steel performance and high accuracy
1.Alloy steel;
2.Low height, good rigidity, high precision, load-deflection resistance is strong;
3.Suitable for electronic belt scale, hopper scale, storage scale, tank scales, mechanics of materials testing machine, etc. weighing devices.
Model 3632 Compression Donut Load Cell features a smooth thru-hole design for use in applications which require the load structure to pass through the cell. The hollow load cells are available for compression only loads in capacities of 25K, 50K and 100K lbs. For optimum performance, this load cell must be mounted between load surfaces which are flat and parallel.
The compact Model MPB Load Cells are designed for applications requiring high capacity yet where space restrictions require that the cell be small in size. The Model MPB will measure compression load forces in ranges between 15,000 to 2,000,000 pounds.
Applications include impact testing and mine shaft roof simulations. The diameter of these load cells range between 1.25 in and 10 in while the height ranges between approximately 0.63 in and 14 in depending on the load range desired.
KWT1D42H is a large range column though-hole force sensor. The large load structure can pass through KWT1D42H, the max diameter of which is 12.7mm.
Compression-torsion composite force sensor;The mutual interference error of the two signals is small;
Low height and easy to install;Accept customized specifications;
Used in automobile press assembly, automated assembly, 3C product testing, new energy product assembly, medical testing,Robotics, mold assembly and other industrial test, measurement and control systems.
| Model Number: | BBM-(M) | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 10-500KG | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
1、S-shape is a common shape of force sensor, which is characterized by simple structure, light weight, convenient installation, high precision, good linearity and high stability. This kind of sensor is usually used to measure light load and medium load.
2、S-Type load cells that receive tension or compression forces. Applications include tank weighing, hoppers, suspended loads and truck scales. S-Type load cells provide superior performance in a compact, versatile package.
3、it can be used in mechanical and electrical integration scales, crane scales, hopper scales and various special application scales and industrial measurement systems.
1、S-shape is a common shape of force sensor, which is characterized by simple structure, light weight, convenient installation, high precision, good linearity and high stability. This kind of sensor is usually used to measure light load and medium load.
2、S-Type load cells that receive tension or compression forces. Applications include tank weighing, hoppers, suspended loads and truck scales. S-Type load cells provide superior performance in a compact, versatile package.
3、it can be used in mechanical and electrical integration scales, crane scales, hopper scales and various special application scales and industrial measurement systems.
1、S-shape is a common shape of force sensor, which is characterized by simple structure, light weight, convenient installation, high precision, good linearity and high stability. This kind of sensor is usually used to measure light load and medium load.
2、S-Type load cells that receive tension or compression forces. Applications include tank weighing, hoppers, suspended loads and truck scales. S-Type load cells provide superior performance in a compact, versatile package.
3、it can be used in mechanical and electrical integration scales, crane scales, hopper scales and various special application scales and industrial measurement systems
