• Capacity: 0-50T
• Sensitivity: 2.0±0.05mV/V
• Non-linearity 0.05% F.S.
• Repeatability 0.03% F.S.
• Material Alloy steel with nickel plated
• Bi-directional tension and compression
• Can be customized

• Capacity: 0-500T
• Sensitivity: 1.0±10%mV/V
• Non-linearity 0.05% F.S.
• Repeatability 0.03% F.S.
• Material Alloy steel with nickel plated
• Bi-directional tension and compression
• Can be customized

• Capacity: 50-500T
• Sensitivity: 2.0±0.05mV/V
• Non-linearity 0.05% F.S.
• Repeatability 0.03% F.S.
• Material Alloy steel with nickel plated
• Bi-directional tension and compression
• Can be customized

이 제품은 고급 합금강 재질로 만들어졌으며, 협소한 공간에도 설치가 가능한 고안정성 센서로, 다양한 산업 자동화 및 정밀 측정 장비에 적합합니다.

이 제품은 고급 합금강으로 제작되어 뛰어난 안정성과 신호 간섭 저항성을 제공하며, 제한된 공간에도 설치가 가능하고 맞춤 제작이 가능합니다. 다양한 산업 현장에서 압력 및 힘 측정 용도로 폭넓게 활용됩니다.

이 센서는 고급 합금강으로 제작되었으며, 안정성이 뛰어나고 간섭에 강합니다. 공간 제약이 있는 환경에서도 설치가 가능하고, 다양한 산업 자동화 및 검사 분야에 적합합니다.

이 제품은 다양한 강철 케이블의 장력을 안정적으로 측정하며, 설치가 쉬워 산업 현장에서 장기적인 모니터링 용도로 폭넓게 활용됩니다.

1,2,3,5,10,20kN Ring Force Sensor FA1028 is a special model of our brand FIBOS FA1-Series, it also belongs to Ring Force Sensor category. FA1028 can be used to measure force 1kN,2kN,3kN,5kN,10kN and 20kN or customized capacity, its Creep(30min),Non-linearity and Repeatability all ≤0.1%F.S. or can be customized, its Hysteresis ≤0.2%F.S. or can also be customized.

10-2000kg Stainless Steel Ring Force Sensor FA115 is a model of our brand FIBOS FA1-Series, Ring Force Sensor FA115 can be used to measure force 10kg,20kg,50kg,100kg,200kg,300kg, 500kg,1000kg and 2000kg capacity, its Creep(30min) ≤0.1%F.S., its Hysteresis and Repeatability both ≤0.2%F.S., and its Non-linearity ≤0.3%F.S..

10-200kN Stainless Steel Ring Force Sensor FA117 is a model of our brand FIBOS FA1-Series, it belongs to Ring Force Sensor category. FA117 can be used to measure force ranges from 10kN, 20kN, 30kN, 50kN, 100kN up to 200kN capacity, its Zero Balance is ±5%mV/V, its Creep(30min),Non-linearity and Repeatability all ≤0.1%F.S., its Hysteresis ≤0.2%F.S..

Force measurement in various small spaces, measurement and control in industries, research and development, etc.

Weighing Capacity Range 0-250ton High Precision Spoke load cell has these functions:

1. Low height, small deformation and small overall dimension

2. Stainless steel material, high temperature can be customized

3. Protection grade IP674. Explosion-proof grade: Ex ia IIC T4 Ga; Ex iaD 20 T1355.

50-500kg 1t Alloy Steel Aluminum Alloy Spoke Type Load Cell FA120A is a model of our brand FIBOS FA1-Series, it belongs to FA120 which is in Spoke Type Load Cell category, FA120A can be used to measure load 50kg,100kg,200kg,500kg and 1t capacity, its Creep(30min) and Repeatability both ≤0.03%F.S., and its Non-linearity and Hysteresis both ≤0.05%F.S..

0.1-30t ≤0.05%F.S. Alloy Steel Miniature Industrial Automation Applied Spoke Type Load Cell FA120B is a model of our brand FIBOS FA1-Series, Spoke Type Load Cell FA120B can be used to measure load 0.1t,0.2t,1t,2t,3t,5t,10t,15t,20t and 30t capacity, its Non-linearity ≤0.05%F.S. and its Repeatability ≤0.03%F.S..

50-70t Spoke Type Load Cell FA120C is a model of our brand FIBOS FA1-Series, it belongs to FA120 which is in Spoke Type Load Cell category, FA120C can be used to measure load 50t and 70t capacity, its Zero Balance range is ±1%F.S., its Creep(30min),Non-linearity,Hysteresis and Repeatability all ≤0.05%F.S..

100-250t Spoke Type Load Cell FA120D belongs to FA120 which is in Spoke Type Load Cell category of our brand FIBOS FA1-Series, FA120D can be used to measure load 100t,150t,200t and 250t capacity, its Input impedance range is 780±20Ω and its Output impedance range is 700±10Ω, its Zero Balance range is ±1%F.S..
