WBTSH-200kg, WBTSH-300kg, WBTSH-500kg, WBTSH-1t, WBTSH-2t, WBTSH-3t, WBTSH-5t
| Capacity(mm) | L | H | W | T | W1 | H1 | L1 |
| 200~300kg | 62 | 80 | 30 | M10*1 | 10 | 47.5 | 17 |
| 500kg | 62 | 80 | 30 | M12*1 | 10 | 47.5 | 17 |
| 1t | 70 | 90 | 30 | M12*1 | 10 | 52.5 | 17 |
| 2t | 71 | 90 | 45 | M16*1.5 | 17.5 | 50 | 17 |
| 3t | 80 | 100 | 50 | M16*1.5 | 19.5 | 58.5 | 17 |
| 5t | 92 | 100 | 58 | M20*2 | 23.5 | 72.5 | 17 |
Features
용량：500, 1000,2000kg
재질 : Alloy steel, stainless steel optional
타입 : Single-Ended Beam
보호등급 : IP67, IP68
Features
용량：100, 200, 300, 500, 750, 1000kg
재질 : alloy steel
타입 : S type
보호등급 : IP67
Features
용량：0.5, 1, 2, 3, 5t
재질 : Alloy steel，stainless steel optional.
타입 : Single-Ended Beam
보호등급 : IP67/IP68
Features
용량：100, 150, 200, 300, 500, 750kg
재질 : Aluminum
타입 : Single Point
보호등급 : IP66
용량：10, 25, 30, 50, 75, 100, 150, 250klb
재질 : Alloy steel
타입 : Double-Ended Shear Beam
보호등급 : IP68
Features
용량：11, 22, 60, 100kg
재질 : stainless steel
타입 : Single Point
보호등급 : IP68/IP69K
Features
용량：550kg, 1.1, 1.76, 2.2, 4.4t
재질 : high-quality stainless steel
타입 : Single-Ended Beam
보호등급 : IP68
Features
용량：20, 30, 50, 100, 300, 500kg
재질 : stainless steel
타입 : Single-Ended Beam
보호등급 : IP68, IP69K
용량：50, 75, 100klb
재질 : Alloy steel
타입 : Double-Ended Shear Beam
보호등급 : IP68
용량：15t
재질 : Alcy steel
타입 : Double-Ended Shear Beam
보호등급 : IP68
Features
용량：50, 100, 250kg, 0.5, 1, 2, 3, 5, 7.5, 10t
재질 : Alloy steel，stainless steel optional
타입 : Single-Ended Beam
보호등급 : IP67/IP68
