65114 Column Force Sensor
Technical parameters
Dimensions
Force measurement in various small spaces, measurement and control in industries, research and development, etc.
The KWT1C25 is a tensile pressure sensor in a compact design. The special structural design makes the height of the sensor only 36 mm, which is an excellent choice for force measurement in a small space, and is very suitable for applications with a large measuring range and a small use space.
Various industrial weighing systems such as testing machines, truck scales, hopper scales, etc.
The ZMME-S is a series of miniature force transducers designed for applications in general test and measurement as well as machine monitoring and control. The threaded construction enables the ZMME-S to be easily assembled into equipment under test where both tension and compression forces require monitoring.
Features:
Capacity 10kg-500kg
In-line threaded
Micro size
Stainless steel construction
Optional features:
Optional output(4-20mA, 0-5V)
KWT1D63 sensor is a tensile and compressive force transducers with good performance and great overload capacity, it has high-precision embedded integrated circuit, when the load on the force sensor can be collected and solved in real time.
The S beam load cell provides good restraint to possible movement of the automation and in many cases. The small size gives excellent performance for high capacity loading. The output is rationalized to facilitate multiple-cell application. ZMSA is contructed of stainless steel and is potted to IP67 providing excellent protection against moisture and humidity.
Features:
Capacity 1kg-100kg
Both tension and compression
Rational outputs
Stainless steel
Optional features:
Hermetically sealed available
This product features a ring-shaped design that provides fast response and long-lasting static accuracy. It is a passive type requiring no external power and can be used in conjunction with equipment such as charge amplifiers.
The ZMHB double-ended mounting provides good restraint to possible movement of the tanks and, in many cases, eliminates the needs for check rods. The shear beam design gives excellent performance for high capacity loading. The ZMHB is constructed of alloy steel and is potted to IP67 providing excellentt protection against moisture and humidity.
Features:
Capacity 1Klb-50Klb
High accuracy
High stability
Nickel plated alloy steel
Optional features:
Stainless steel construction
The ZMMC2 brake pedal force sensor is designed to measure load applied to the brake, accelerator or clutch pedal. Zhimin’s brake pedal load cells are manufactured to be of excellent quality, so that your application will be reliable, durable, accurate and precise.
Features：
Capacity 500-2000N
High accuracy
Low profile
Nickel plated alloy steel
Optional features：
Optional output(4-20mA,0-5V)
ZMMA-CS is miniature type force sensor for both of compression and tension usage.
Features:
Capacity 2N,3N,5N,10N,20N,30N,50N
Compact size
Stainless steel construction
Both compression and tension
Optional features:
0-5V, 4-20mA output signal
