Features
- Available Capacity: 5kg, 10kg, 20kg
- Anodized aluminum body
Applications
- Low profile platform scale
- Medical scale
- Kitchen scale
Dimensions
Specifications
| Capacity | 5kg, 10kg, 20kg |
| Accuracy class | 0.05% F·S |
| Rated output | 1.0 ± 20%mV/V |
| Zero balance | ±0.1mV/V |
| Creep | ±0.1 % F·S/2min |
| Non-linearity | ±0.1 % F·S |
| Hysteresis error | ±0.1 % F·S |
| Repeatability | ±0.1 % F·S |
| Temp. effect on output | ±0.1% F·S/10ºC |
| Temp. effect on zero | ±2% F·S/10ºC |
| Insulation resistance | ≥ 2000 MΩ |
| Excitation voltage | ≤ 6 VDC |
| Operating temp. range | -10ºC ~+40ºC |
| Safe overload | 150 % F·S |
| Connecting cable | Φ8x150mm |
| Load cell material | Aluminum alloy |
