JB4-HX711
Features
- 24-bit Analog to Digital converter with programmable Gain
- 2-wire Serial Interface
- Selectable data rate of 10Hz or 80Hz
- Plug and play connectivity with on-board connectors
- Arduino / Raspberry Pi compatible
- Low-power operation in Power Down Mode
Applications
- Weight systems
- Stress testing machines
- Commercial sensing machines
Accessories
- Cables with matching connectors
Specifications
| Power Supply | 2.6 – 5.5V |
| Nominal Current | 1.5mA |
| Power Down Current | 0.5uA |
| Common Mode Input | GND + 1.2V VCC – 1.3V |
| Output Settling Time | 400 ms |
|
Input Offset Drift (Gain = 128) |
0.2 mV |
|
Temperature Drift (Gain = 128) |
±5 ppm/°C |
| Input Common Mode Rejection (Gain = 128) | 100 dB |
| Power Supply Rejection (Gain = 128) | 100 dB |
