Santwell / SQC / 시어 빔 로드셀

We are specialized in manufacturing 15 ton Shear Beam Load Cell Waterproof Force Sensor Canister Load Cells 20 Ton CMAX, etc. for over many years. Manufactured following the strict management system, our 15 ton Shear Beam Load Cell Waterproof Force Sensor Canister Load Cells 20 Ton CMAX has gained a reliable quality. Before its launch, it has passed the tests based on international rules and is certified by several authorities. Santwell is worth the investment for those customers seeking business opportunities. In aspect of the product design, our design team always pays close attention to the customers’ taste and industry trends. Thanks to this, our 15 ton Shear Beam Load Cell Waterproof Force Sensor Canister Load Cells 20 Ton CMAX can fully attract people’s attention with its unique appearance. Moreover, it is excellent performance, making it worth the investment.

Warranty: / Customized support: ODM
Place of Origin: Zhejiang, China Brand Name: Santwell
Model Number: SQC Rated Load: 100KG
Sensitivity: 2.0000±0.002mv/v Total Error: ±0.02%F.S
Creep(30 minutes): ±0.02%F.S Recommended Excitation Voltage: 5V-12V(AC or DC)
Maximum Excitation Voltage: 15V(AC or DC) Zero Balance: ±1%F.S
Insulation Impedance: ≥5000MΩ Safe Overload: ±150%F.S
UItimate Overload: ±200%F.S















Add to Wishlist
Share it:

Ningbo Santwell Import & Export Co., Ltd offers an exceptional quality range of Pressure Sensors. The quality of the SQC alloy steel material 1ton for platform scale and floor scale manufacturers prices of load cells shear beam load cell is at the leading level in the industry and is inseparable from the hard work and innovation of outstanding technical personnel. We strictly stick to the concept of scientific design, which contributes to the unique appearance and easy-to-use performance of our Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells. Also, we never use inferior raw materials and ensure they are all tested by our QC inspectors, thereby, guaranteeing Pressure Sensors quality. We believe that our product with so many advantages can bring benefits to all customers.

Specification: 500kg, 1t, 2t, 3t

shipping: Support Sea freight · Land freight

Customization: Customized logo (Min. Order: 100 Pieces),Customized packaging (Min. Order: 100 Pieces),Graphic customization (Min. Order: 100 Pieces)

Technical Parameter

Rated Load
KG
 100KG
Sensitivity
 mV/V
2.0000±0.002
Total Error %F.S ±0.02
Creep(30minutes) %F.S ±0.02
Recommended Excitation Voltage V
5 ~12 (AC or DC)
Maximum Excitation Voltage V
15 (AC or DC)
Zero Balance %F.S ±1
Input Impedance Ω
380±10
Output Impedance Ω
350±5
Insulation Impedance MΩ ≥5000
Safe Overload %F.S 150
Ultimate Overload %F.S 200
Operating Temperature Range ℃
(-30~+70)
Compensated Temperature Range
℃
 (-20~+60)
Temperature Effect On Load ℃
±0.02%F.S/10
Temperature Effect On Zero ℃ ±0.02%F.S/10
Construction Alloy steel
Protection Class IP67&IP68
Citation GB/T7551-2008/OIML R60
Mode of Connection
Input+E:Red Input-E:Black Output+S:Green Output-S:White
